11. EXPLODED VIEW & REPLACEMENT PART LIST
- 207 -
Level Ref No Part Name Part Number Spec Color Remark
7 L140 INDUCTOR,CHIP ELCH0001022 56 nH,J ,1005 ,R/TP ,Pb Free
7 L141 INDUCTOR,CHIP ELCH0001009 1.2 nH,S ,1005 ,R/TP ,
7 L142 CAP,CHIP,MAKER ECZH0000844 68 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 L143 INDUCTOR,CHIP ELCH0005019 68 nH,J ,1005 ,R/TP ,
7 L144 INDUCTOR,CHIP ELCH0005020 1 nH,S ,1005 ,R/TP ,
7 L145 INDUCTOR,CHIP ELCH0005019 68 nH,J ,1005 ,R/TP ,
7 L146 INDUCTOR,CHIP ELCH0001421 47 nH,J ,1005 ,R/TP ,PBFREE
7 L700 INDUCTOR,SMD,POWER ELCP0008001 4.7 uH,M ,2.5*2.0*1.0 ,R/TP ,
7 L701 INDUCTOR,SMD,POWER ELCP0008001 4.7 uH,M ,2.5*2.0*1.0 ,R/TP ,
7 L702 INDUCTOR,SMD,POWER ELCP0008001 4.7 uH,M ,2.5*2.0*1.0 ,R/TP ,
7 L903 INDUCTOR,CHIP ELCH0001002 5.6 nH,J ,1005 ,R/TP ,chip inductor PBFREE
7 L904 INDUCTOR,CHIP ELCH0005012 3.9 nH,S ,1005 ,R/TP ,
7 L905 INDUCTOR,CHIP ELCH0001003 6.8 nH,J ,1005 ,R/TP ,chip inductor PBFREE
7 L906 INDUCTOR,CHIP ELCH0001009 1.2 nH,S ,1005 ,R/TP ,
7 L907 INDUCTOR,CHIP ELCH0001009 1.2 nH,S ,1005 ,R/TP ,
7 L911 CAP,CERAMIC,CHIP ECCH0000183 1.8 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP
7R102 RES,CHIP,MAKER ERHZ0000495 56 ohm,1/16W ,J ,1005 ,R/TP
7R103 RES,CHIP,MAKER ERHZ0000212 12 Kohm,1/16W ,F ,1005 ,R/TP
7R104 RES,CHIP,MAKER ERHZ0000310 680 ohm,1/16W ,F ,1005 ,R/TP
7R105 RES,CHIP,MAKER ERHZ0000408 110 ohm,1/16W ,J ,1005 ,R/TP
7R106 RES,CHIP,MAKER ERHZ0000408 110 ohm,1/16W ,J ,1005 ,R/TP
7R107 RES,CHIP,MAKER ERHZ0003801 5.1 ohm,1/16W ,J ,1005 ,R/TP
7R110 RES,CHIP ERHY0013101 2.7 ohm,1/16W ,J ,1005 ,R/TP
7R114 RES,CHIP,MAKER ERHZ0000206 10 ohm,1/16W ,F ,1005 ,R/TP
7R118 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
7 R123 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
7 R125 RES,CHIP,MAKER ERHZ0000443 2200 ohm,1/16W ,J ,1005 ,R/TP
7 R126 RES,CHIP,MAKER ERHZ0000443 2200 ohm,1/16W ,J ,1005 ,R/TP
7 R127 RES,CHIP,MAKER ERHZ0000203 10 Kohm,1/16W ,F ,1005 ,R/TP
7 R128 RES,CHIP,MAKER ERHZ0000351 11800 ohm,1/16W ,F ,1005 ,R/TP
7 R129 RES,CHIP ERHY0005902 5.62 Kohm,1/16W ,F ,1005 ,R/TP
7 R130 RES,CHIP ERHY0005902 5.62 Kohm,1/16W ,F ,1005 ,R/TP
7 R131 RES,CHIP,MAKER ERHZ0000490 51 ohm,1/16W ,J ,1005 ,R/TP
7 R132 RES,CHIP,MAKER ERHZ0000402 10 ohm,1/16W ,J ,1005 ,R/TP
7 R200 RES,CHIP ERHY0000162 215K ohm,1/16W,F,1005,R/TP
7 R201 RES,CHIP,MAKER ERHZ0000204 100 Kohm,1/16W ,F ,1005 ,R/TP
7 R202 RES,CHIP,MAKER ERHZ0000493
51 Kohm,1/16W ,J ,1005 ,R/TP
To Next Page
