11. EXPLODED VIEW & REPLACEMENT PART LIST
- 208 -
Level Ref No Part Name Part Number Spec Color Remark
7 R203 RES,CHIP ERHY0000186 2.2 Kohm,1/16W ,F ,1005 ,R/TP
7 R204 RES,CHIP,MAKER ERHZ0000441 22 ohm,1/16W ,J ,1005 ,R/TP
7 R205 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
7 R206 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
7 R207 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
7 R208 RES,CHIP,MAKER ERHZ0000437 2 Kohm,1/16W ,J ,1005 ,R/TP
7 R209 RES,CHIP,MAKER ERHZ0000443 2200 ohm,1/16W ,J ,1005 ,R/TP
7R210 RES,CHIP,MAKER ERHZ0000443 2200 ohm,1/16W ,J ,1005 ,R/TP
7R211 RES,CHIP,MAKER ERHZ0000204 100 Kohm,1/16W ,F ,1005 ,R/TP
7 R300 RES,CHIP,MAKER ERHZ0000402 10 ohm,1/16W ,J ,1005 ,R/TP
7 R301 RES,CHIP,MAKER ERHZ0000402 10 ohm,1/16W ,J ,1005 ,R/TP
7 R302 RES,CHIP,MAKER ERHZ0000405 10 Kohm,1/16W ,J ,1005 ,R/TP
7 R303 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R304 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R305 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R306 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
7 R307 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
7 R308 RES,CHIP ERHY0000290 300K ohm,1/16W,J,1005,R/TP
7 R500 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R501 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R701 RES,CHIP,MAKER ERHZ0004201 121000 ohm,1/16W ,F ,1005 ,R/TP
7 R702 RES,CHIP,MAKER ERHZ0000439 200 Kohm,1/16W ,J ,1005 ,R/TP
7 R703 RES,CHIP,MAKER ERHZ0000405 10 Kohm,1/16W ,J ,1005 ,R/TP
7 R704 RES,CHIP,MAKER ERHZ0000495 56 ohm,1/16W ,J ,1005 ,R/TP
7 R705 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
7 R706 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
7 R707 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP
7 R708 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R800 RES,CHIP,MAKER ERHZ0000443 2200 ohm,1/16W ,J ,1005 ,R/TP
7 R801 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
7 R802 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
7 R909 INDUCTOR,CHIP ELCH0004711 22 nH,J ,1005 ,R/TP ,
7 U100 IC EUSY0300501
QFN ,56 PIN,R/TP ,GSM, WCDMA Single RF
Transceiver, 8X8X0.9
7 U106 IC EUSY0300401
QFN ,48 PIN,R/TP ,WCDMA Dual Receiver IC for USA,
7X7X0.9
7U200 IC EUSY0360401
CSP ,409 ,R/TP ,WCDMA/GSM/GPRS/EDGE/HSDPA BB
to avoid IPR#686 ,; ,IC,Digital Baseband Processor
To Next Page
