11. EXPLODED VIEW & REPLACEMENT PART LIST
- 209 -
Level Ref No Part Name Part Number Spec Color Remark
7U300 IC EUSY0300101
WQFN ,10 PIN,R/TP ,Small package Dual SPDT analog
Switch, PB-Free
7U301 IC EUSY0160001
MicroStar Junior ,15 PIN,R/TP ,1.1W Class-D Mono Audio
AMP
7U302 IC EUSY0333402
FBGA ,225 PIN,ETC ,2G(LB/128Mx16/2.7V)
NAND+1G(8Mx4x32) SDRAM ,; ,IC,MCP
7 U500 IC EUSY0345901
WDFN ,8 PIN,R/TP ,2X2 Dual LDO 2.8V/2.8V
300mA/300mA ,; ,IC,LDO Voltage Regulator
7 U701 IC EUSY0306302 BCCS ,84 PIN,R/TP ,7x7, MSMC(1.2V), pbfree
7 U801 IC EUSY0333701 TLLGA ,8 PIN,R/TP ,OVP
7 U802 FILTER,EMI/POWER SFEY0006501 SMD ,3 TERMINAL EMI FILTER
7 X100 VCTCXO EXSK0007802
19.2 MHz,1.5 PPM,10 pF,SMD ,3.3*2.5*1.0 , ,; , ,2PPM
,2.8V , , , , ,SMD ,P/TP
7 X700 X-TAL EXXY0024301
32.768 KHz,20 PPM,12.5 pF,70 Kohm,SMD ,3.2*1.5*0.9
,-40'C ~ +85'C, C0 1.05pF, C1 fF ,; ,32.768 ,20PPM ,12.5
, , ,SMD ,R/TP
6WSYY00 SOFTWARE WSYY0705501 CU920-MSM-V10h-FEB-05-2008-ATT-US
4SAJY00 PCB ASSY,SUB SAJY0027501 Black 32
5SAJB00 PCB ASSY,SUB,INSERT SAJB0014701
5SAJE00 PCB ASSY,SUB,SMT SAJE0021401 Black
6SAJC00
PCB ASSY,SUB,SMT
BOTTOM
SAJC0020201 Black
7ANT100 ANTENNA,GSM,FIXED SNGF0027401
3.0 ,-2 dBd, ,BLUETOOTH, SMD, 8.0*2.0*1.3 ,; ,SINGLE
,-2.0 ,50 ,3.0
7 C100 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C101 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
7 C102 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
7 C104 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7 C105 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
7 C106 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7 C107 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C108 CAP,CERAMIC,CHIP ECCH0005603 2.2 uF,10V ,K ,X5R ,TC ,1608 ,R/TP
7 C109 CAP,CHIP,MAKER ECZH0004402
100000 pF,16V ,Z ,X7R ,TC ,1005 ,R/TP , , ,[empty]
,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
7 C110 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C111 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C112 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C113 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 C114 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C115 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7 C116 CAP,CERAMIC,CHIP ECCH0004904
1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
