11. EXPLODED VIEW & REPLACEMENT PART LIST
LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
Level Ref No Part Name Part Number Spec Color Remark
7 C117 CAP,TANTAL,CHIP ECTH0004807
10 uF,10V ,M ,STD ,1608 ,R/TP ,; , ,[empty] ,[empty] , ,-
55TO+125C , ,[empty] ,[empty] ,[empty] ,[empty]
7 C118 CAP,TANTAL,CHIP ECTH0004807
10 uF,10V ,M ,STD ,1608 ,R/TP ,; , ,[empty] ,[empty] , ,-
55TO+125C , ,[empty] ,[empty] ,[empty] ,[empty]
7 C119 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7C120 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7C121 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP
7C122 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7C123 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 CN100
CONNECTOR,BOARD TO
BOARD
ENBY0018501 10 PIN,.4 mm,STRAIGHT , ,H=0.9,HEADER
7 CN102 CONNECTOR,FFC/FPC ENQY0008602 6 PIN,0.5 mm,ETC ,AU ,H:1.2MM
7 J100 CONN,SOCKET ENSY0016501 6 PIN,ETC , ,2.54 mm,H=1.5
7 L101 INDUCTOR,CHIP ELCH0001022 56 nH,J ,1005 ,R/TP ,Pb Free
7 L102 RES,CHIP,MAKER ERHZ0000401 0 ohm,1/16W ,J ,1005 ,R/TP
7 R100 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R102 RES,CHIP,MAKER ERHZ0000422 15 Kohm,1/16W ,J ,1005 ,R/TP
7 R103 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R104 RES,CHIP,MAKER ERHZ0000533 7.5 Kohm,1/16W ,J ,1005 ,R/TP
7 R105 RES,CHIP,MAKER ERHZ0000530 5.1 Kohm,1/16W ,J ,1005 ,R/TP
7 R106 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R107 RES,CHIP,MAKER ERHZ0000412 1200 ohm,1/16W ,J ,1005 ,R/TP
7 R108 RES,CHIP,MAKER ERHZ0000412 1200 ohm,1/16W ,J ,1005 ,R/TP
7 U100 IC EUSY0084701 SSOP5-P-A ,6 PIN,R/TP ,Inverter, Pb Free
7 U101 MODULE,ETC SMZY0010701 Bluetooth RF Module, 4.5*3.2*1.2
7 U102 DIODE,TVS EDTY0009201
1.6*1.6*0.6 ,5 V,150 W,R/TP , ,; ,5 ,6 ,15 ,40 ,- ,[empty]
,R/TP ,6P ,4
7 U103 IC EUSY0295501 TQFN , PIN,R/TP ,6 BLU+2 LDO+1 Flash LED Drv, 4*4
7 U104 IC EUSY0337101
CSP ,12 PIN,R/TP ,Touchscreen Controller IC , ,IC,A/D
Converter
6 SAJD00 PCB ASSY,SUB,SMT TOP SAJD0023001 Black
7 CN101
CONNECTOR,BOARD TO
BOARD
ENBY0016501 50 PIN,0.4 mm,STRAIGHT ,AU ,1.5T,HEADER,MALE
7 SPJY00 PCB,SUB SPJY0050301 FR-4 ,0.5 mm,BUILD-UP 6 ,CU915 SUB ,; , , , , , , , , ,
4 SJMY00 VIBRATOR,MOTOR SJMY0008410 3 V,.08 A,10*2.7 ,17mm elco8000 ,; ,3V , , ,12500 , , , , 11 F
4 SNGF00 ANTENNA,GSM,FIXED SNGF0027601
3.0 ,-2.0 dBd, ,GSM850+EGSM+DCS+PCS+W-BAND
II+W-BAND V, INTERNAL ,; ,QUAD ,-2.0 ,50 ,3.0
21 H
4 SNGR00
ANTENNA,GSM,RETRACTA
BLE
SNGR0000601
4.5 ,4.5 ,-7 dBd,-7 dBd,BLACK ,MediaFLO, E131.56mm,
R48.11mmm H5.16mm, NO HINGE
23 L
4 SUSY00 SPEAKER SUSY0025701 PIN ,8 ohm,90 dB, mm, ,; , , , , , ,18*13*3.6T ,PIN 12 J
4SVCY00 CAMERA SVCY0012401 CMOS ,MEGA ,2M AF FPCB, Micron 1/4
