9. CALIBRATION
- 148 -
Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
This is for example.
You can check “C:\LGE\Tachyon\Model\D690\Setting Guide”
B
A
2A
2B
2 3 4
USB cable (A-B type)
(P/No : BJAY0020060)
GPIB cable (IEEE-488)
(P/No : BJAY0020058)
RF Connection Cable
COM3
COM1
Shield Box USB Cable
A
2
2A
2B
3
4
