2. PERFORMANCE

- 5 -

Only for training and service purposes

LGE Internal Use Only

2. PERFORMANCE

LG-D690n Product SPEC

1. Product Name

LG-D690N : WCDMA850/900/1900/2100+EGSM/GSM850/DCS/PCS

(HSDPA 21.1Mbps (Cat.14) / HSUPA 5.76Mbps (Cat.6) / GPRS Class 12 / EDGE Class 12

Downlink(Rx) Only)

2. Supporting Standard

Item Feature Comment

Supporting Standard WCDMA(FDD1,2,5,8)/

EGSM/GSM850/DCS1800/PCS1900

Frequency Range WCDMA(FDD1) TX : 1920 – 1980 MHz

WCDMA(FDD1) RX : 2110 – 2170 MHz

WCDMA(FDD2) TX : 1852.4– 1907.6 MHz

WCDMA(FDD2) RX : 1932.4 – 1987.6 MHz

WCDMA(FDD5) TX : 824 – 849 MHz

WCDMA(FDD5) RX : 869 – 894 MHz

WCDMA(FDD8) TX : 880 – 915 MHz

WCDMA(FDD8) RX : 925 – 960 MHz

EGSM TX : 880 – 915 MHz

EGSM RX : 925 – 960 MHz

GSM850 TX : 824 – 849 MHz

GSM850 RX : 869 – 894 MHz

DCS1800 TX : 1710 – 1785 MHz

DCS1800 RX : 1805 – 1880 MHz

PCS1900 TX : 1850 – 1910 MHz

PCS1900 RX : 1930 – 1990 MHz

Application Standard

WAP 2.0

3. Main Parts : Solution

Item

Part Name

Comment

AP Chip

MT6582 (MTK)

PMIC Chip

MT6323 (MTK)

RF Chip

MT6166 (MTK)
