10. DISASSEMBLE GUIDE
- 161 -
Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
3. Disassemble REAR
1
2
3
4
Be carefully
C-Clip damage
1. Using the tool or hand make gap between Rear Cover and Front Cover
2. Insert spatula, in the bottom right of the phone and unhook right, top and left
(Back view)
