LG D690 - Page 17

2. PERFORMANCE
- 17 -
Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D690n Product SPEC
15
9) Bluetooth specification (continued)
C/I Performance
DH1
PRBS9
< 11 dB ( Co-Channel, -60dBm@ BER0.1% )
< 0 dB (C/I @1MHz, -60dBm@ BER 0.1%)
< -30 dB ( C/I @2MHz, -60dBm@ BER 0.1% )
< -40 dB ( C/I @≥3MHz, -67dBm@ BER0.1% )
< -9 dB ( C/I @Image, -67dBm@ BER 0.1%)
< -20 (dB C/I @1MHz Image, -67dBm@ BER 0.1%)
Blocking Performance
DH1
PRBS9
< -67 dBm (-10dBm @ 30M ~2 GHz)
< -67 dBm (-27dBm @ 2 ~ 2.4 GHz)
< -67 dBm (-27dBm @ 2.5 ~ 3 GHz)
< -67 dBm (-10dBm @ 3 ~ 12.75 GHz)
Intermodulation
Performance
DH1
PRBS9
< -
64 dBm (Δf = +5MHz (CW), Δf = +10MHz (BT), BER @
0.1%)
< -64 dBm (Δf = -5MHz (CW), Δf = -1
0MHz (BT), BER @
0.1%)
Maximum Input Level
DH1
PRBS9
> -20 dBm (BER @ 0.1%)
10) GPS receiver specification
Item
Specification
Receive Frequency
1574.42 MHz ~ 1576.42 MHz
Sensitivity Test
Success rate ≥ 60% @ -154 dBm
11) Signal Bar
Cell Power
[dBm]
GSM WCDMA Comment
Bar 54
-91 ±
2dBm -86 ± 2dBm
1. Call Connected &
CPIPH Level=-3.3
2. WCDMA: RSSI,
GSM: RSSI
Bar 43
-96 ±
2dBm -90 ± 2dBm
Bar 32
-99 ±
2dBm -96 ± 2dBm
Bar 21
-103 ±
2dBm -100 ± 2dBm
Bar 10
-105 ±
2dBm -106 ± 2dBm
