14) Battery Icon Display
LG-D690n Product SPEC
17
14) Battery Icon Display
Battery Bar Specification Battery Bar Specification
Bar 20(Full)
98%이
상
Bar 9 -> Bar 8 43% -> 42%
Bar 20 -> Bar 19 98% -> 97% Bar 8 -> Bar 7 38% -> 37%
Bar 19 -> Bar 18 93% -> 92% Bar 7 -> Bar 6 33% -> 32%
Bar 18 -> Bar 17 88% -> 87% Bar 6 -> Bar 5 28% -> 27%
Bar 17 -> Bar 16 83% -> 82% Bar 5 -> Bar 4 23% -> 22%
Bar 16 -> Bar 15 78% -> 77% Bar 4 -> Bar 3 16% -> 15%
Bar 15 -> Bar 14 73% -> 72% Bar 3 -> Bar 2 13% -> 12%
Bar 14 -> Bar 13 68% -> 67% Bar 2 -> Bar 1 8% -> 7%
Bar 13 -> Bar 12 63% -> 62% Bar 1 -> Bar 0 3% -> 2%
Bar 12 -> Bar 11 58% -> 57% Power off
1%이
하
Bar 11 -> Bar 10 53% -> 52% Low battery pop-up 15% , 5%, 0%
Bar 10 -> Bar 9 48% -> 47%
Power off voltage : SOC 1%(3.4V) ±0.1V
15) Basic Performance
Item Specification Target Test condition
DOU
(Day Of Usage)
1.0 1.0
LTE Profile Ver. 4.0 기준
Heat
Emmision
(ΔT) *
WCDMA Δ18℃ Δ18℃ WCDMA TX 23dBm
GSM
Δ15℃ Δ15℃
GSM TX 33dBm(EGSM)
or 30dBm(DCS, PCS)
Handset
RLR
(Acoustic)
-10±3 dB
(Vol. Max)
-10dB Torso type 3.3
Handset RLR
(Acoustic)
Earphone
RLR
(Ear
Acoustic)
-7±3 dB
(Vol. Max)
-7dB Torso type 3.3
Earphone RLR
(Ear Acoustic)
15) Basic Performance
Power o voltage : SOC 1%(3.4V) ±0.1V
