3. TROUBLE SHOOTING
- 71 -
Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
START
Check the MIC signal by Loopback test
Reconnect the main PCB
Change theearjack socket(J6100)
Change the MT6323(U4100).
Is voice signal OK?
Change the main PCB
END
END
END
No
No
No
Yes
Yes
Yes
