LG DP547 - Front Panel; Rear Panel

Getting Started
9
Getting Started
1
Front Panel
a
Disc Tray
b
MIC. (Microphone jack)
(DP547 only)
c
VOL.
S
/
W
(Volume controller)
(DP547 only)
d
Display window
e
Remote sensor
f R
(Open/Close)
g T
(Play/Pause)
h 1/!
(Power)
i
USB Port (DP542/DP547 only)
Rear Panel
a
Power Cord
b
AUDIO OUT (Left/Right)
c
VIDEO OUT
d
COMPONENT VIDEO OUT (Y P
B
P
R
)
e
DIGITAL AUDIO OUT (COAXIAL)
 
h i g
