58
1. Remove a Screw.
2. Remove the Optical Disk Drive.
1M2.5X0.45P,4.5mm,
5mm
FAB300651011
QtySpecificationFRU No.No.
Ch5. Removing and replacing a part
■ 1040 Optical Disk Drive
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. Hard Disk Drive(1020) c. Memory(1030)
To Next Page
