LG F1 - WLAN Card

59
1. Remove a Screw, then disconnect the Antenna Cable.
2. Remove the WLAN Card.
Ch5. Removing and replacing a part
■ 1050 WLAN Card
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. Hard Disk Drive(1020) c. Memory(1030) d. Optical Disk Drive(1040)
