LG F1 - USB Sub Board

79
1. Remove a Screw.
1M2.5X0.45P,4.5mm,
5mm
FAB300651011
QtySpecificationFRU No.No.
Ch5. Removing and replacing a part
■ 1150 USB Sub Board
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. Hard Disk Drive(1020) c. Memory(1030) d. Optical Disk Drive(1040)
e. WLAN Card(1050) f. MDC Card(1060) g. Fan Assembly(1070) h. Retainer(1080)
i. Keyboard(1090) j. Button Sub Board(1100) k. Display Module(1110) l. Main Board(1120)
