78
1. Disconnect the Microphone Connector, then remove the Microphone.
Ch5. Removing and replacing a part
■ 1140 Microphone
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. Hard Disk Drive(1020) c. Memory(1030) d. Optical Disk Drive(1040)
e. WLAN Card(1050) f. MDC Card(1060) g. Fan Assembly(1070) h. Retainer(1080)
i. Keyboard(1090) j. Button Sub Board(1100) k. Display Module(1110) l. Main Board(1120)
To Next Page
