LG F1 - Fan Assembly

61
1. Remove 5 Screws.
5M2.5X0.45P,4.5mm,
5mm
FAB300651011
QtySpecificationFRU No.No.
2. Disconnect the Fan Assembly Cable, then remove the Fan Assembly.
Ch5. Removing and replacing a part
■ 1070 Fan Assembly
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. Hard Disk Drive(1020) c. Memory(1030) d. Optical Disk Drive(1040)
e. WLAN Card(1050) f. MDC Card(1060)
