LG F1 - Part Lists; Ch 6. Part List

87
REV.04
,SYS/POWER SUPPLY ADAPTOR/90W/90-264Vin/4.74A/19Vout/LI SHIN/LSE0202C1990/FOR MS-
1037,RoHS COMPLIANCE
EAY32531401NACA1
,SYS/BATTERY PACK/LITHIUM-
ION/SMP/925C2450F/PANASONIC/3.6V/2200mAh/6cells/10.8V/4400mAH/18650/BLACK/FOR SQU-
524,RoHS COMPLIANCE
EAC32576901 NBATM
2200mAhEAC32576902NBATM
,SYS/MODULE/INVERTER/SAMPO/YIVNMS0020D11--/FOR AU AND LG 15inch PANEL/FOR MS-
1034L1,RoHS COMPLIANCE
EAY32711501NNVE1
TS64MSQ64V5J 0IMMR00233BNMEM1
TS64MSQ64V6JEAN33410401NMEM1
,SYS RAM MODULE,DDR2
SDRAM,333(667)MHz,512MB,SODIMM,TRANSCEND/TS64MSQ64V6J,64MX64bit/1.8V/HYNIX
CHIP,RoHS COMPLIANCE
EAN32932101NMEM1
,SYS RAM MODULE,DDR2 SDRAM,333(667)MHz,512MB,SODIMM,TWINMOS/8D-
23JN5JEATP,64MX64bit/1.8V/ELPIDA CHIP,RoHS COMPLIANCE
EAN32872001NMEM1
ASSY(bezel
+bracket)
??? /HLDS/GCC-4244N, S74-1303090-H44ABQ31509002NODD1
ASSY(bezel
+bracket)
Active,MS-16121L1,Black,Super-Multi,,FOR HLDS, S7A-1322010-H44ABQ31509001NODD1
BUY&SELL/LG,SYS/HDD/SATA-150/HITACHI/HTS541010G9SA00/2.5 inch/100GB/5400RPM/FOR MS-
1034L1,RoHS COMPLIANCE
6744C00158BNHDD1
80GB;5400rpm (RoHS)6744C00147CNHDD1
60GB;5400rpm (RoHS)6744C00146CNHDD1
BUY&SELL/LG,SYS/HDD/SATA-150/2.5 inch/100GB/5400RPM/FUJITSU/MHV2100BH/FOR MS-
1034L1,RoHS COMPLIANCE
6744C00157ANHDD1
80GB;5400rpm (RoHS)6744C00156ANHDD1
60GB;5400rpm (RoHS)6744C00155ANHDD1
15.4" WXGA( Glare,RoHS type)6304FLP155ENLCD1
CPU Merom (Napa refresh) Intel 1.66GHZ Cache 2MB 667MHZ FCPGA-478pinEAN32961201NCPU1
CPU Merom (Napa refresh) Intel 1.83GHZ Cache 2MB 667MHZ FCPGA-478pinEAN32960101NCPU1
Celeron 1.6G 533MHZ (QKIT)EAN32927801NCPU1
Celeron 1.73G 533 MHZ (QKIS) EAN31735101NCPU1
BUY&SELL/LG,CPU YONAH,INTEL/QPUD 1.73G,,1.73GHz,FCPGA-478pin,1MB 533MHz FSB DUO
CORE YONAH,RoHS COMPLIANCE
EAN32181401NCPU1
RemarksSpecificationPart NoLocation
Chapter 6. Part lists
Ch6. Part lists
