1. Remove a Screw.
1M2.5X0.45P,4.5mm,
5mm
FAB300651011
QtySpecificationFRU No.No.
2. Remove the Speaker Cable.
Ch5. Removing and replacing a part
■ 1130 Main Board
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. Hard Disk Drive(1020) c. Memory(1030) d. Optical Disk Drive(1040)
e. WLAN Card(1050) f. MDC Card(1060) g. Fan Assembly(1070) h. Retainer(1080)
i. Keyboard(1090) j. Button Sub Board(1100) k. Display Module(1110) l. Main Board(1120)
To Next Page
