3. IC101 MICOM
• PIN DESCRIPTION
Pin Name I/O Description Option
V
SS
1, V
SS
2
V
SS
3
- - Power supply pin
No
V
DD
1, V
DD
2
V
DD
3
- + Power supply pin
No
Port 0
P00 to P07
I/O • 8-bit I/O port
• I/O specifiable in 4-bit units
• Pull-up resistor can be turned on and off in 4-bit units
• HOLD release input
• Port 0 interrupt input
• Shared Pins
P05 : Clock output (system clock / can selected from sub clock)
P06 : Timer 6 toggle output
P07 : Timer 7 toggle output
Yes
Port 1
P10 to P17
I/O • 8-bit I/O port
• I/O specifiable in 1-bit units
• Pull-up resistor can be turned on and off in 1-bit units
• Pin functions
P10 : SIO0 data output
P11 : SIO0 data input/bus I/O
P12 : SIO0 clock I/O
P13 : SIO1 data output
P14 : SIO1 data input/bus I/O
P15 : SIO1 clock I/O
P16 : Timer 1 PWML output
P17 : Timer 1 PWMH output/beeper output
Ye
s
Port 2 • 8-bit I/O port
• I/O specifiable in 1-bit units
• Pull-up resistor can be turned on and off in 1-bit units
• Other functions
P20: INT4 input/HOLD reset input/timer 1 event input/timer 0L capture input/
timer 0H capture input/INT6 input/timer 0L capture 1 input
P21 to P23 : INT4 input/HOLD reset input/timer 1 event input/timer 0L capture input/
timer 0H capture input
P24: INT5 input/HOLD reset input/timer 1 event input/timer 0L capture input/
timer 0H capture input/INT7 input/timer 0H capture 1 input
P25 to P27: INT5 input/HOLD reset input/timer 1 event input/timer 0L capture input/
timer 0H capture input
• Interrupt acknowledge ty
pe
Rising Falling
Rising/
Falling
H level L lev
el
INT4
INT5
INT6
INT7
enable
enable
enable
enable
enable
enable
enable
enable
enable
enable
enable
enable
disable
disable
disable
disable
disable
disable
disable
disable
P20 to P27
I/O Ye
s
