5. IC704 PWM
• PIN DESCRIPTION
Name Pin NO. Type Description
Power and Ground
PLL_AVDD 6 Analog
Power
PLL analog power supply.
PLL_AVSS 8 Analog
Ground
PLL
analog ground.
PLL_DVDD 3 PLL
Power
PLL digital power supply.
PLL_DVSS 2 PLL
Ground
PLL digit
al ground.
DVDD 13, 34, 42,
66, 80, 91
Power Core power supply
.
DVSS 14, 35, 43,
63, 81, 92
Ground Core digit
al ground.
IO_VDD 4,
10, 22, 29, 39, 47,
56, 65, 72, 94
Power I/O power supply. 3.3V Digital power supply.
IO_VSS 1, 5, 7, 9, 21,
28, 38, 44, 50,
53, 57, 60, 64,
69, 73, 85, 95
Ground I/O digital ground.
Reset and Clock
/RESET 96 I H/W reset signal. Active Low Schmitt-Trigger input.
The Schmitt-Trigger input allows a slowly rising input to reset the
chip reliably. The RESET signal must be asserted ‘Low’ during
power up. De-assert ‘High’ for normal operation.
XIN 86 Analog Cryst
al Oscillator input pin.
XOUT 87 Analog Cryst
al Oscillator output pin.
PCM Audio Input/Output Interface
MBCK 11 I/O PCM bit clock input/output of main 8-channel audio.
User can select the master/slave mode of this signal.
Schmitt-Trigger i
nput.
MLRCK 12 I/O PCM Word clock (left-right clock) input/output of main 8-channel
audio. User can select the master/slave mode of this signal.
Schmitt-Trigger i
nput.
MSDIN [3:0] 15, 16, 17, 18 I PCM serial data input of main 8-channel audio.
Schmitt-Trigger i
nput.
SBCK 19 I/O PCM bit clock input/output of 8-channel audio.
User can select the master/slave mode of this signal.
Schmitt-Trigger i
nput.
SLRCK 20 I/O PCM word clock (left-right clock) input/output of sub 8-channel
audio. User can select the master/slave mode of this signal.
Schmitt-Trigger i
nput.
SSDIN [3:0] 23, 24, 25, 26 I/O PCM serial data input of sub-channel audio.
User can set this sub-channel data input pins to PCM serial data
output pins. See the Control Register Description part.
Schmitt-Trigger i
nput
