LG Hydro Kit - How to Connect Wirings

Installation
28 Hydro Kit
Remove the box cover of electric parts and connect the wiring.
Remove the box cover of electric parts and connect the wiring.
CAUTION
When connecting the power and
communication cable, always
use the terminal connector
(O-ring, Y-ring).
!
Make sure to tighten so that
the screw of the terminal does
not get loose.
How to connect wirings
• For Medium Temperature
• For High Temperature
Communication
cable
Communication
cable
Power
cable
Power cable
Ground
Communication
cable
Power cable
Communication
cable
Power cable
8 HP 4 HP
Make sure to tighten so that
the screw of the terminal does
not get loose.
CAUTION
When connecting the power and
communication cable, always
use the terminal connector
(O-ring, Y-ring).
!
