2. DSP OUTPUT I2S WAVEFORM (IC600)
DSP_I2S_BCK Waveform (12.288 MHz) - PIN40
DSP_I2S_FL_RL/C_FW/FR_RR/BL_BR Waveform
& Rising time - PIN44, 49, 52
DSP_I2S_LRCK Waveform (192 KHz) - PIN39
DSP_I2S_FL_RL/C_FW/FR_RR/BL_BR Waveform
& Rising time - PIN44, 49, 52
