6. PCB PICTURE
6-1 Main PCB
P/No & MFG
Drawer
Swing
EBR770425**
(2013.05~)
CON8
CON7
CON5
CON3 CON2
CON1
CON201
EBR766714**
2013 05
(.~)
CON7
CON9
CON4
CON5
CON8
CON3 CON1
