10-3 Damper
Function
How to
Measure
< Damper Circuit >
< extension >
Check the ,
Standard
Damper
Test P oin t s
Red and Yellow
Result
373 ~ 456Ω
Test P oin t s
Blue and White
Result
373 ~ 456Ω
Check the resistance between connectors 1,3 and 2,4 .It means
check whether or not applying an electric current. If there is
resistance, it means the damper not inferiority
1
Blue
1
Blue
2
Red
3
White
3
White
1 3
Check the ,
2 4
Check the ,
1 3
3
Yellow
The damper supplies the cold air from the freezer to the refrigerator
section.
38
