Page #55 background image
Bank is
not full
HALL Sensor
Output Signals
ON
OFF
HALL Sensor
Output Signals
ON
OFF
Bank is
full
Ice checking AXIS LEVEL 30°
-8°
-0°
-10°
-32° -41° -53°
-58° -80° -160°
-170°
Lock Lock
Icemaking
original point
Ice ejection
MAXIMUM TILTING POINT
Ice checking
AXIS
A B C
9±3 sec
8±3 sec
2±1 sec
Level Return
Conditions
Horizontal
Conditions
54
