39
Reference
GeneralCD/DVDVideo
Amplifier
Speakers
Tuner
FM
Specifications
Power supply Refer to main label
Power consumption Refer to main label
Mass 5.5 kg
External dimensions (W x H x D) 430 x 93 x 350 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
Signal system NTSC 525/60
Frequency response (audio) 150 Hz to 18 kHz
Signal-to-noise ratio (audio) More than 75 dB (1 kHz, NOP -6 dB, 20 kHz LPF/A-Filter)
Dynamic range (audio) More than 70 dB
Harmonic distortion (audio) 0.5 % (1 kHz, at 1W position) (20 kHz LPF)
Video input 1.0 V (p-p), 75 Ω, negative sync., RCA jack x 2
Video output 1.0 V (p-p), 75 Ω, negative sync., RCA jack x 1
S-video output (Y) 1.0 V (p-p), 75 Ω, negative sync., Mini DIN 4-pin x 1
(C) 0.3 V (p-p), 75 Ω
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack x 1
(Pb)/(Pr) 0.7 V (p-p), 75 ohms, RCA jack x 2
Tuning Range 87.5 - 108.0 MHz
Intermediate Frequency 10.7 MHz
Signal-to Noise Ratio 60 dB (Mono)
Frequency Response 150 - 8,000 Hz
Tuning Range 522 - 1,620 kHz or 520 - 1,720 kHz
Intermediate Frequency 450 kHz
Stereo mode 155W + 155W (Rated Output Power 130W, 4Ω at 1 kHz, THD 10 %)
Surround mode Front: 155W + 155W (Rated Output Power 130W, THD 10 %)
Centre*: 155W
Surround*: 155W + 155W (Rated Output Power 130W, 4Ω at 1 kHz,
THD 10 %)
Subwoofer*: 225W (Rated Output Power 180W, 3Ω at 30 Hz, THD 10 %)
Inputs VIDEO 1, VIDEO 2, COAXIAL AUDIO, OPTICAL AUDIO
Outputs S-VIDEO, MONITOR, PHONES: (32 Ω, 1.0 V)
Front Speaker Rear Speake Center speaker Woofer Speaker
(LHS-96PAF) (LHS-96PAS) (LHS-96PAC) (LHS-96PAW)
Type
2 Way 3 Speaker 1 Way 1 Speaker 2 Way 3 Speaker 1 Way 1 Speaker
Impedance 4 Ω 4 Ω 4 Ω 3 Ω
Frequency Response 90 - 18,000 Hz 120 - 20,000 Hz 80 - 18,000 Hz 40 - 1,500Hz
Sound Pressure Level 836 dB/W (1m) 82 dB/W (1m) 86 dB/W (1m) 82 dB/W (1m)
Rated Input Power 155 W 155 W 155 W 225 W
Max. Input Power 310 W 310 W 310 W 450 W
Net Dimensions (W x H x D)
300x1350x300mm 120x248x96mm 500x160x155mm 236x435x391mm
Net Weight 5.35kg
0.87kg 1.73kg 10.5kg
(*
Depending on the sound mode
settings and the source, there
may be no sound output.)
AM
