LG Low Ambient Control Kit - Unit Placement and Clearances

Installation Method of Snow Hood and Air Damper
Installation manual 25
3. Unit Placement and Clearances
1. Outdoor units should be located in an area protected from prevailing winds. (shown below)
In high wind locations it may be advisable to locate the units within a walled area.
Top View
Prevailing wind
Building Wall
Outdoor Unit
H ≤ discharge
of air damper
2. If the units are surrounded by an enclosure, the discharge of the air damper must direct the air out and over the
enclosure walls to prevent air recirculation.
