Installation Method
8 Low Ambient Control Kit
1. IO Module Installation Method
Installation Method
① Separate front panel from outdoor unit.
② Separate front cover of control box.
③ Assemble IO Module and bracket.
④
Connect the connection wires according to the instructions. (Please refer to Setting and Using Method)
ڸ
ڹ
ں
+
ڻ
Main board connector
CAUTION
Be sure to turn off outdoor unit power before installation.
