Fig 8
Fig 8-1
Fig 8-2
8 Lever switch (Fig 8)
8-1 remove the Lever switch interminals. (Fig 8-1)
8-2 remove the screw and then the floater. (Fig 8-2)
7. DISASSEMBLELY
