2-3
USING YOUR RANGE
To turn on a single surface unit
(Right Rear, Left Rear)
1. Press ON/OFF pad for the desired element.
2. Press ( + / – ) pad to choose the desired setting.
To turn on a dual surface unit
(Left Front)
1. Press ON/OFF pad
2. Press the SELECT pad as needed to select
the desired burner size. When first selected, 9”
size is on. The light above the SELECT pad
indicates which size surface unit is on.
2. Press ( + / – ) pad to choose the desired setting.
To turn on a triple surface unit
(Right Front)
1. Press ON/OFF pad
2. Press the SELECT pad as needed to select
the desired burner size. When first selected,
12” size is on. The light above the SELECT
pad indicates which size surface unit is on.
2. Press ( + / – ) pad to choose the desired setting.
Note:
• Each time a pad is pressed a beep will sound.
• The power level decreases or increases by 0.5
from 9.0 through 3.0. (by 0.2 from 3.0 through 1.0)
• Lo is the lowest power level available.
• “HS” will appear when the unit is hot to touch
To set the warming zone control
1. Press ON/OFF pad at the warming zone.
2. Press ( + / – ) pad to choose the desired setting.
Note:
• Each time a pad is pressed a beep will sound.
• The controls for the warming zone allow for 5
different heat settings : Lo~Hi
• “HS” will appear when the unit is hot to touch.
1. SETTING THE CLOCK
2. START, CLEAR/OFF AND ON/OFF PAD
1. Touch START pad to start oven.
2. Touch CLEAR/OFF pad to cancel a program
during cooking or Erase during programming.
3. Touch ON/OFF pad to start or cancel the
surface unit.
3. TO TURN ON/OFF THE OVEN LIGHT
The oven light automatically turns ON when the
door is opened. The oven light may also be
manually turned ON or OFF by pressing the
OVEN LIGHT pad
Note: The oven light cannot be turned on if self-clean feature
is active.
4. TIMER ON/OFF
To cancel timer at any time, touch TIMER ON/OFF pad.
Note:
1. If you press TIMER ON/OFF pad once, this allows you to
select "minutes"
(for example: if you press “5” and “6”, it means 56 minutes)
2. If you press TIMER ON/OFF pad twice, this allows you to
select "seconds"
(for example: if you press “5” and “6”, it means 56 seconds)
5. SETTING PAD: 6 types of category
1) CONVECTION AUTO CONVERSION
1. Press SETTING pad once
2. Press “1” pad for ENABLE
or “2” pad for DISABLE
3. Press START pad.
2) THERMOSTAT ADJUSTMENT
The oven temperature can be adjusted from
-35°F (-19°C) to 35°F (19°C).
Note: The thermostat adjustments made with this feature will
just change Bake, Convection Bake and Convection
Roast temperature.
To increase the oven temperature:
1. Press SETTING pad twice
2. Press the desired temperature
3. Press START pad.
To decrease the oven temperature:
1. Press SETTING pad twice
2. Press the desired temperature
3. Press the SETTING pad once
4. Press START pad
CLEAR
/OFF
CLOCK
Desired
Time
START
TIMER
ON/OFF
Desired
time
TIMER
ON/OFF
A
B
D
D
