3-8
COMPONENT ACCESS
1. Unplug range or disconnect power.
2. Pull the range out of its mounting location so that
you can access the rear of the unit.
3. Remove lamp, controller and back cover
(See the page 3-2)
4. Remove 4 screws and a powercord.
5. Remove 4 screws and detach the bake heater
cover from the range. Disconnect 2 wiring (2
bake heater receptacles)
6. Bend a insulation ceramic wool up and bend 2
flanges up.
7. Carefully pull the hidden bake element out of the
range.
REMOVING THE HIDDEN BAKE ELEMENT
Bake Heater Cover
Insulation ceramic wool
2 flanges
To Next Page
