3-16
COMPONENT ACCESS
REMOVING THE OVEN DOOR GASKET
1. Open the oven door to its fully down position.
2. Pull the oven door gasket clips out of the liner
holes until all of the clips are removed.
3. Pull the ends of the gasket out of the liner holes.
REASSEMBLY NOTE: When you install the new
gasket, make sure that all of the clips are seated in
their liner holes, and that the ends of the gasket are
pushed fully into their holes. Use the pointed end of
a pencil to push the gasket ends into the holes.
Door gasket
Gasket clip
Liner Hole
WARNING
• DISCONNECT power supply cord
from the outlet before servicing.
• Replace all panels and parts before
operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
CAUTION
• Be careful when you work on the
electric range handling the sheet
metal part.
- Sharp edge may be present and you can cut
yourself.
