Page #54 background imageLoading...
Page #54 background image
Left Front Outer
Left Front Inner
Range Of the resistance
Right Front Outer
yes
Replace the Main PCB
9-9
CHECKING FLOW CHART BY FAILURE
Heater Resistance[Ω]
Approximately
Center Rear 47
Center Rear 47
LF: 1400W(Inner)
1800W(Outer)
47
32
RF: 1100W(Single)
2200W(Dual)
3000W(Triple)
50
50
68.3
Center Rear 570
