LG LTCS24223B /04 User Manual

2) Refrigerator Sensor Error
No
1
noitcACVS & tluseRwolf gnikcehC
<Temperature table-1>
(1) To (2)
23°F
°C
32°F
°C
41°F
°C
50°F
°C
59°F
°C
Result
38
30
24
19.5
16
The sensor is determined by
the temperature.
For example, 30
indicates 32°F.
0
Short
Open
Normal
Change the sensor
Check the resistance of
the sensor wires back to
the main PCB.
if they are open between
the main PCB and
connector it will be
necessary to replace the
refrigerator
Check the Temp and
resistance (Table-1)
Result SVC Action
Check for loose connection in CON8.
2
1.- Unplug connector from CON8.
2.- Check resistance in wires White to
White.
Firmly plugged
Loose
Go to step 2
Plug firmly, then check again.
Problem persist?
YES: Go to step 2.
NO: Explain to customer.
Result SVC Action
COLDESTCOLD
- 41 -

LG LTCS24223B /04 Specifications

General

Type	freestanding
Style	top freezer
Color	black, smooth black
Total Capacity	23.8 cubic feet
Refrigerator Capacity	6.2 cubic feet
Freezer Capacity	6.20 cubic feet
Humidity Controlled Crispers	yes
Defrost System	automatic
Quick Freeze	no
Number of Refrigerator Door Bins	yes
Temperature Control	digital
Interior Light	led
Ice Maker	yes
Water Filter	no
Air Filter	no
Door Alarm	yes
Smart Home	no
Annual Energy Consumption	501 kilowatt hours
Voltage	120 volts
Current	20 amperes

Weight and Dimensions

Depth	33.375 inches
Height	68.5 inches
Width	32.75 inches
Net Weight	224 pounds
