3. DISASSEMBLY
Middle
Hinge Bracket
Fig. 4
Fig. 5
Fig. 6
TOOLS NEEDED
REMOVING THE FREEZER DOOR
Fig. 1
Fig. 2
Hinge Pin
Middle Hinge Bracket
Fig. 3
Carefully lift up the freezer door. Place the door on a non-
scratching surface.
WARNING
WARNING
Excessive Weight Hazard:
Use two or more people to remove and install the
refrigerator doors. Failure to do so can result in back or
other injury.
for bottom door hinge).
Remove the top-hinge cover by gently prying it with a flat
head screwdriver.
the three bolts and lift off the top hinge. Set parts aside.
Electrical Shock Hazard
before installing. Failure to do so could result in serious
injury or death.
injured or receive an electrical shock.
REMOVING THE REFRIGERATOR DOOR
Loosen and remove the two bolts using a phillips head
screwdriver.
Remove the middle hinge bracket.
Carefully lift up the door. Place the door on a non scratching
surface.
To Next Page
