ACCESSORIES
Air Guides
(ZAGDKA51A and ZAGDKA52A)
Optional air guides are available for Multi V 5 outdoor units to change the discharge direction from vertical to horizontal.
Use ZAGDKA51A air guides with the following models:
6-ton Outdoor Units ARUM072BTE5 / ARUM072DTE5.
Use ZAGDKA52A air guides with the following models:
8-ton to 20-ton Outdoor Units ARUM096BTE5 / ARUM096DTE5, ARUM121BTE5 / ARUM121DTE5, ARUM144BTE5 / ARUM144DTE5,
ARUM168BTE5 / ARUM168DTE5, ARUM192BTE5 / ARUM192DTE5, ARUM216BTE5 / ARUM216DTE5, ARUM241BTE5 / ARUM241DTE5.
Hail Guard Kits
(ZHGDKA51A and ZHGDKA52A)
Optional hail guard kits help protect the heat exchangers in Multi V 5 outdoor units.
Each kit includes:
Use ZHGDKA51A with the following Multi V 5 models:
6-ton Outdoor Units ARUM072BTE5 / ARUM072DTE5.
Use ZHGDKA52A with the following Multi V 5 models:
8-ton to 20-ton Outdoor Units ARUM096BTE5 / ARUM096DTE5, ARUM121BTE5 / ARUM121DTE5, ARUM144BTE5 / ARUM144DTE5,
ARUM168BTE5 / ARUM168DTE5, ARUM192BTE5 / ARUM192DTE5, ARUM216BTE5 / ARUM216DTE5, ARUM241BTE5 / ARUM241DTE5.
Contact an LG Sales Representative to verify how many kits are needed for the dual and triple frame combination outdoor units.
• Right wind baffle
• Left wind baffle
• Rear wind baffle
• (50) #10 x 1/2 self-drilling hex head screws
Low Ambient Baffle Kits
(ZLABKA51A and ZLABKA52A)
Optional low ambient baffle kits allow for Multi V 5 outdoor unit operation down to -9.9°F in cooling mode. When used with heat recovery
operation, low ambient cooling to -9.9°F is possible only when all indoor units are operating in cooling mode. The low ambient wind baffle kit
does not impact synchronous operating range.
Each kit includes:
Use ZLABKA51A with the following Multi V 5 models:
6-ton Outdoor Units ARUM072BTE5 / ARUM072DTE5.
Use ZLABKA52A with the following Multi V 5 models:
8-ton to 20-ton Outdoor Units ARUM096BTE5 / ARUM096DTE5, ARUM121BTE5 / ARUM121DTE5, ARUM144BTE5 / ARUM144DTE5,
ARUM168BTE5 / ARUM168DTE5, ARUM192BTE5 / ARUM192DTE5, ARUM216BTE5 / ARUM216DTE5, ARUM241BTE5 / ARUM241DTE5.
Contact an LG Sales Representative to verify how many kits are needed for the dual and triple frame combination outdoor units.
• Right wind baffle
• Left wind baffle
• Rear wind baffle
• Top discharge elbow with motorized damper and 24V damper
actuator
• (50) #10 x 1/2 self-drilling hex head screws
• Sealtite connector (for routing of actuator control and power wiring
down to outdoor unit electrical box)
• PRVC2 Control kit is a required accessory (sold separately)

LG Multi V 5 Specifications

General

Type	VRF (Variable Refrigerant Flow)
Refrigerant	R410A
Compressor Type	Inverter Scroll Compressor
Outdoor Unit Fan Type	Axial Fan
Cooling Capacity	22.4 kW to 270 kW
Energy Efficiency	High
Operating Range	Cooling: -5°C to 48°C
Power Supply	380-415V, 50/60Hz
Heat Exchanger Type	Microchannel
Control Type	Centralized Control
Indoor Unit Options	Cassette, Wall Mounted, Ducted
Heat Recovery	Available
Warranty	Varies by region (typically 5 years compressor, 1-2 years parts)
