ELECTRICAL DATA
208-230V Outdoor Unit Electrical Data
Nom.
Tons
Unit Model
Nos.
Compressor (Comp.)
Condenser Fan
Motor(s)
MCA MOCP RFA
Comp.
Qty.
Motor Amps
Fan
Qty.
Amps
Motor RLA (Ea.)
FLA (Ea.)
Frame Frame Frame
123 1 2 3 1 2 3
Frame
123
Frame
123
Comp.
A
Comp.
B
Comp.
A
Comp.
B
Comp.
A
Comp.
B
6.0 ARUM072BTE5 1 14.1 - - - - - 1 5.0 - - 22.6 - - 35 - - 35 - -
8.0 ARUM096BTE5 1 16.4 - - - - - 2 8.0 - - 28.5 - - 40 - - 40 - -
10.0 ARUM121BTE5 1 18.3 - - - - - 2 8.0 - - 30.9 - - 40 - - 40 - -
12.0 ARUM144BTE5 2 19.8 18.3 - - - - 2 8.0 - - 51.1 - - 70 - - 70 - -
14.0 ARUM168BTE5 2 21.2 19.1 - - - - 2 8.0 - - 53.6 - - 70 - - 70 - -
16.0 ARUM192BTE5 2 23.3 20.8 - - - - 2 8.0 - - 57.9 - - 80 - - 80 - -
18.0 ARUM216BTE5 2 24.3 21.9 - - - - 2 8.0 - - 60.3 - - 80 - - 80 - -
20.0 ARUM241BTE5 2 25.6 23.2 - - - - 2 8.0 - - 63.2 - - 80 - - 80 - -
22.0 ARUM264BTE5 3 21.2 19.1 16.4 - - - 4 8.0 8.0 - 53.6 28.5 - 70 40 - 70 40 -
24.0 ARUM288BTE5 3 23.3 20.8 16.4 - - - 4 8.0 8.0 - 57.9 28.5 - 80 40 - 80 40 -
26.0 ARUM312BTE5 3 24.3 21.9 16.4 - - - 4 8.0 8.0 - 60.3 28.5 - 80 40 - 80 40 -
28.0 ARUM336BTE5 3 24.3 21.9 18.3 - - - 4 8.0 8.0 - 60.3 30.9 - 80 40 - 80 40 -
30.0 ARUM360BTE5 4 24.3 21.9 19.8 18.3 - - 4 8.0 8.0 - 60.3 51.1 - 80 70 - 80 70 -
32.0 ARUM384BTE5 4 24.3 21.9 21.2 19.1 - - 4 8.0 8.0 - 60.3 53.6 - 80 70 - 80 70 -
34.0 ARUM408BTE5 4 24.3 21.9 23.3 20.8 - - 4 8.0 8.0 - 60.3 57.9 - 80 80 - 80 80 -
36.0 ARUM432BTE5 4 23.3 20.8 18.3 - 18.3 - 6 8.0 8.0 8.0 57.9 30.9 30.9 80
40 40 80 40 40
38.0 ARUM456BTE5 4 24.3 21.9 18.3 - 18.3 - 6 8.0 8.0 8.0 60.3 30.9 30.9 80 40 40 80 40 40
40.0 ARUM480BTE5 5 24.3 21.9 19.8 18.3 18.3 - 6 8.0 8.0 8.0 60.3 51.1 30.9 80 70 40 80 70 40
42.0 ARUM504BTE5 5 24.3 21.9 21.2 19.1 18.3 - 6 8.0 8.0 8.0 60.3 53.6 30.9 80 70 40 80 70 40
For component model nos. see the specification tables on p. 10-14.
Voltage tolerance is 187V to 253V.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOCP) is calculated as follows: (Largest motor FLA x 2.25) + (Sum of
other motor FLA) rounded down to the nearest standard fuse size.
RFA = Recommended Fuse Amps.
*SCCR rating: 5kA RMS Symmetrical.
Table 11: 208-230V, 60Hz, 3-Phase Outdoor Units.

LG Multi V 5 Specifications

General

Type	VRF (Variable Refrigerant Flow)
Refrigerant	R410A
Compressor Type	Inverter Scroll Compressor
Outdoor Unit Fan Type	Axial Fan
Cooling Capacity	22.4 kW to 270 kW
Energy Efficiency	High
Operating Range	Cooling: -5°C to 48°C
Power Supply	380-415V, 50/60Hz
Heat Exchanger Type	Microchannel
Control Type	Centralized Control
Indoor Unit Options	Cassette, Wall Mounted, Ducted
Heat Recovery	Available
Warranty	Varies by region (typically 5 years compressor, 1-2 years parts)
