LG Multi V 5

ODU PRODUCT DATA | 21
Outdoor Unit Product Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
ELECTRICAL DATA
460V Outdoor Unit Electrical Data
Table 12: 460V, 60Hz, 3-Phase Outdoor Units.
Nom.
Tons
Unit Model
Nos.
Compressor (Comp.)
Condenser Fan
Motor(s)
MCA MOCP RFA
Comp.
Qty.
Motor Amps
Fan
Qty.
Amps
Motor RLA (Ea.)
FLA (Ea.)
Frame Frame Frame
123 1 2 3 1 2 3
Frame
123
Frame
123
Comp.
A
Comp.
B
Comp.
A
Comp.
B
Comp.
A
Comp.
B
6.0 ARUM072DTE5 1 7.8 - - - - - 1 3.0 - - 12.8 - - 20 - - 20 - -
8.0 ARUM096DTE5 1 9.1 - - - - - 2 5.0 - - 16.4 - - 25 - - 25 - -
10.0 ARUM121DTE5 1 10.7 - - - - - 2 5.0 - - 18.4 - - 25 - - 25 - -
12.0 ARUM144DTE5 2 10.3 8.5 - - - - 2 5.0 - - 26.4 - - 35 - - 35 - -
14.0 ARUM168DTE5 2 11.4 9.2 - - - - 2 5.0 - - 28.5 - - 35 - - 35 - -
16.0 ARUM192DTE5 2 14.8 12.2 - - - - 2 5.0 - - 35.7 - - 50 - - 50 - -
18.0 ARUM216DTE5 2 15.5 13.9 - - - - 2 5.0 - - 38.3 - - 50 - - 50 - -
20.0 ARUM241DTE5 2 16.9 15.3 - - - - 2 5.0 - - 41.4 - - 50 - - 50 - -
22.0 ARUM264DTE5 3 11.4 9.2 9.1 - - - 4 5.0 5.0 - 28.5 16.4 - 35 25 - 35 25 -
24.0 ARUM288DTE5 3 14.8 12.2 9.1 - - - 4 5.0 5.0 - 35.7 16.4 - 50 25 - 50 25 -
26.0 ARUM312DTE5 3 15.5 13.9 9.1 - - - 4 5.0 5.0 - 38.3 16.4 - 50 25 - 50 25 -
28.0 ARUM336DTE5 3 15.5 13.9 10.7 - - - 4 5.0 5.0 - 38.3 18.4 - 50 25 - 50 25 -
30.0 ARUM360DTE5 4 15.5 13.9 10.3 8.5 - - 4 5.0 5.0 - 38.3 26.4 - 50 35 - 50 35 -
32.0 ARUM384DTE5 4 15.5 13.9 11.4 9.2 - - 4 5.0 5.0 - 38.3 28.5 - 50 35 - 50 35 -
34.0 ARUM408DTE5 4 15.5 13.9 14.8 12.2 - - 4 5.0 5.0 - 38.3 35.7 - 50 50 - 50 50 -
36.0 ARUM432DTE5 4 14.8 12.2 10.7 - 10.7 - 6 5.0 5.0 5.0 35.7 18.4 18.4 50
25 25 50 25 25
38.0 ARUM456DTE5 4 15.5 13.9 10.7 - 10.7 - 6 5.0 5.0 5.0 38.3 18.4 18.4 50 25 25 50 25 25
40.0 ARUM480DTE5 5 15.5 13.9 10.3 8.5 10.7 - 6 5.0 5.0 5.0 38.3 26.4 18.4 50 35 25 50 35 25
42.0 ARUM504DTE5 5 15.5 13.9 11.4 9.2 10.7 - 6 5.0 5.0 5.0 38.3 28.5 18.4 50 35 25 50 35 25
For component model nos. see the specification tables on p. 15-19.
Voltage tolerance is 414V to 528V.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOCP) is calculated as follows: (Largest motor FLA x 2.25) + (Sum of
other motor FLA) rounded down to the nearest standard fuse size.
RFA = Recommended Fuse Amps.
*SCCR rating: 5kA RMS Symmetrical.
