LG Multi V 5 Engineering Manual

ODU PRODUCT DATA | 19
Outdoor Unit Product Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
Combination Unit Model Number
ARUM432DTE5
36.0 Ton
ARUM456DTE5
38.0 Ton
ARUM480DTE5
40.0 Ton
ARUM504DTE5
42.0 Ton
Individual Component Model Numbers
ARUM121DTE5 +
ARUM121DTE5 +
ARUM192DTE5
ARUM121DTE5 +
ARUM121DTE5 +
ARUM216DTE5
ARUM121DTE5 +
ARUM144DTE5 +
ARUM216DTE5
ARUM121DTE5 +
ARUM168DTE5 +
ARUM216DTE5
Cooling Performance
Nominal Cooling Capacity (Btu/h)
1
432,000 456,000 480,000 504,000
Rated Cooling Capacity (Btu/h)
2
412,000 434,000 458,000 480,000
Heating Performance
Nominal Heating Capacity (Btu/h)
1
486,000 513,000 540,000 567,000
Rated Heating Capacity (Btu/h)
2
460,000 488,000 513,000 539,000
Operating Range
Cooling (°F DB)
5 to 122 5 to 122 5 to 122 5 to 122
Heating (°F WB)
-13 to +61 -13 to +61 -13 to +61 -13 to +61
Synchronous — Cooling Based (°F DB)
14 to 81 14 to 81 14 to 81 14 to 81
Synchronous — Heating Based (°F WB)
14 to 61 14 to 61 14 to 61 14 to 61
Compressor
Inverter Quantity
HSS DC Scroll x 4 HSS DC Scroll x 4 HSS DC Scroll x 5 HSS DC Scroll x 5
Oil/Type
PVE / FVC68D PVE / FVC68D PVE / FVC68D PVE / FVC68D
Fan (Top Discharge)
Type
Propeller (BLDC) Propeller (BLDC) Propeller (BLDC) Propeller (BLDC)
Motor Output (kW) x Qty.
0.90x2 + 0.90x2 + 0.90x2 0.90x2 + 0.90x2 + 0.90x2 0.90x2 + 0.90x2 + 0.90x2 0.90x2 + 0.90x2 + 0.90x2
Motor/Drive
Brushless Digitally Controlled / Direct
Operating Range (RPM)
Cooling
0 - 1,150 0 - 1,150 0 - 1,150 0 - 1,150
Heating
80 - 1,150 80 - 1,150 80 - 1,150 80 - 1,150
Maximum Air Volume (CFM)
33,900 33,900 33,900 33,900
Unit Data
Refrigerant Type
R410A R410A R410A R410A
Refrigerant Control/Location
EEV / Indoor Unit EEV / Indoor Unit EEV / Indoor Unit EEV / Indoor Unit
Factory Charge lbs. of R410A
23.2 + 23.2 + 30.9 23.2 + 23.2 + 37.5 23.2 + 26.5 + 37.5 23.2 + 26.5 + 37.5
Max. No. Indoor Units/System
3
64 64 64 64
Sound Pressure dB(A)
4
66.0 66.0 67.0 67.0
Net Unit Weight (lbs.)
507 + 507 + 659 507 + 507 + 666 507 + 639 + 666 507 + 639 + 666
Shipping Weight (lbs.)
534 + 534 + 688 534 + 534 + 694 534 + 666 + 694 534 + 666 + 694
Communication Cables
5,6
2 x 18 2 x 18 2 x 18 2 x 18
Heat Exchanger
Material and Fin Coating
Copper Tube / Aluminum Fin and Black Coated Fin™ / Hydrophilic
Rows/Fins per inch
2/17 x 2 + 3/17 2 / 17 x 2 + 3 / 17 2 / 17 + 3 / 17 x 2 2 / 17 + 3 / 17 x 2
Piping for Heat Recovery Operation
7
Liquid Line Connection (in., OD)
1/2 & 1/2 & 5/8 Braze 1/2 & 1/2 & 5/8 Braze 1/2 & 1/2 & 5/8 Braze 1/2 & 5/8 & 5/8 Braze
Low Pressure Vapor Line Conn. (in., OD)
1-1/8 & 1-1/8 & 1-1/8 Braze 1-1/8 & 1-1/8 & 1-1/8 Braze 1-1/8 & 1-1/8 & 1-1/8 Braze 1-1/8 & 1-1/8 & 1-1/8 Braze
High Pressure Vapor Line Conn. (in., OD)
3/4 & 3/4 & 1-1/8 Braze 3/4 & 3/4 & 1-1/8 Braze 3/4 & 7/8 & 1-1/8 Braze 3/4 & 7/8 & 1-1/8 Braze
Piping for Heat Pump Operation
7
Liquid Line Connection (in., OD)
1/2 & 1/2 & 5/8 Braze 1/2 & 1/2 & 5/8 Braze 1/2 & 1/2 & 5/8 Braze 1/2 & 5/8 & 5/8 Braze
Vapor Line Connection (in., OD)
1-1/8 & 1-1/8 & 1-1/8 Braze 1-1/8 & 1-1/8 & 1-1/8 Braze 1-1/8 & 1-1/8 & 1-1/8 Braze 1-1/8 & 1-1/8 & 1-1/8 Braze
Table 10: Triple Frame 460V Outdoor Units.
GENERAL DATA
92XWGRRU8QLW6SHFL¿FDWLRQV
1
Nominal capacity applied with non-ducted indoor units, and is rated 0 ft. above sea level with 25 ft. of
refrigerant line per indoor unit and a 0 ft. level difference between outdoor and indoor units. All capaci-
ties are net with a Combination Ratio between 95–105%.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF
wet bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and
59ºF wet bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
2
Rated capacity is certified under AHRI Standard 1230. See www.ahrinet.org for information.
3
The System Combination Ratio must be between 50–130%.
4
Sound pressure levels are tested in an anechoic chamber under ISO Standard 3745.
5
Communication cable between Master ODU to Slave ODU(s), and Master ODU to IDUs / HRUs to be
18 AWG, 2-conductor, twisted, stranded, shielded. Ensure the communication cable shield is properly
grounded to the Master ODU chassis only.
Do not ground the ODU to IDUs / HRUs communication
cable at any other point. Wiring must comply with all applicable local and national codes.
6
Power wiring is field provided, solid or stranded, and must comply with the applicable local and nation-
al codes. See page 21 for detailed electrical data.
7
LG requires that LATS software be used on all projects to ensure correct line sizing. Designer must
verify the shop drawing design against the as built design using LATS. Contractor must also use LG
manufactured Y-Branch and Header Kits only.

LG Multi V 5 Specifications

General

Type	VRF (Variable Refrigerant Flow)
Refrigerant	R410A
Compressor Type	Inverter Scroll Compressor
Outdoor Unit Fan Type	Axial Fan
Cooling Capacity	22.4 kW to 270 kW
Energy Efficiency	High
Operating Range	Cooling: -5°C to 48°C
Power Supply	380-415V, 50/60Hz
Heat Exchanger Type	Microchannel
Control Type	Centralized Control
Indoor Unit Options	Cassette, Wall Mounted, Ducted
Heat Recovery	Available
Warranty	Varies by region (typically 5 years compressor, 1-2 years parts)
