LG Multi V 5

100 | PERFORMANCE DATA
MULTI V 5 Outdoor Unit Performance Data Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
Combination
(%)
Outdoor air
temp.
Indoor Air Temp. °F DB/°F WB
59 61 64 67 70 73 76 80
°F DB °F WB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI TC Pl
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
130%
-12.6 -13.0 56.0 3.45 56.0 3.78 56.0 4.28 55.8 4.69 55.6 5.11 55.6 5.53 55.6 5.74 55.6 6.02
-7.0 -7.6 61.0 3.95 61.0 4.28 61.0 4.77 60.8 5.19 60.6 5.60 60.6 6.03 60.6 6.24 60.6 6.51
-4.0 -4.4 64.0 4.24 64.0 4.58 64.0 5.07 63.8 5.49 63.6 5.90 63.6 6.33 63.6 6.54 63.6 6.81
0.0 -0.4 67.7 4.61 67.7 4.94 67.7 5.44 67.5 5.86 67.3 6.27 67.3 6.70 67.3 6.90 67.3 7.18
5.0 4.5 72.3 5.07 72.3 5.40 72.3 5.90 72.1 6.32 71.8 6.73 71.8 7.16 71.8 7.36 71.8 7.64
10.0 9.0 76.9 5.53 76.9 5.86 76.9 6.36 76.7 6.78 76.4 7.19 76.4 7.62 76.4 7.82 76.4 8.10
15.0 14.0 81.5 5.98 81.5 6.32 81.5 6.81 81.2 7.23 80.9 7.64 80.9 8.07 80.9 8.27 80.9 8.55
20.0 19.0 86.2 6.45 86.2 6.78 86.2 7.28 85.9 7.70 85.6 8.11 85.6 8.26 85.6 8.08 85.6 7.85
25.0 23.0 90.8 6.91 90.8 7.24 90.8 7.74 90.5 7.98 90.2 8.22 90.2 7.87 90.2 7.70 90.2 7.47
30.0 28.0 95.4 7.37 95.4 7.70 95.4 8.20 95.1 8.01 94.8 7.81 94.3 7.48 93.1 7.31 91.6 7.08
35.0 32.0 100.0 8.24 100.0 8.16 100.0 8.06 99.7 7.73 99.4 7.40 97.4 7.09 93.4 6.92 88.0 6.70
40.0 36.0 104.7 8.28 104.7 7.97 104.7 7.51 104.3 7.25 104.0 6.99 98.7 6.70 92.9 6.53 85.1 6.32
45.0 41.0 108.2 7.36 108.2 7.21 108.2 6.97 106.6 6.77 105.1 6.57 98.7 6.30 92.9 6.14 85.1 5.93
47.0 43.0 108.2 7.17 108.2 7.02 108.2 6.79 106.6 6.59 105.1 6.40 98.7 6.14 92.9 5.98 85.1 5.77
50.0 46.0 108.2 6.90 108.2 6.76 108.2 6.54 106.6 6.35 105.1 6.16 98.7 5.91 92.9 5.76 85.1 5.56
55.0 51.0 108.2 6.48 108.2 6.34 108.2 6.14 106.6 5.96 105.1 5.79 98.7 5.55 92.9 5.41 85.1 5.22
60.0 56.0 108.2 6.02 108.2 5.90 108.2 5.71 106.6 5.54 105.1 5.38 98.7 5.16 92.9 5.03 85.1 4.85
120%
-12.6 -13.0 55.6 3.95 55.6 4.28 55.6 4.77 55.4 4.94 55.2 5.11 55.2 5.75 55.2 5.89 55.2 6.07
-7.0 -7.6 60.5 4.44 60.5 4.77 60.5 5.27 60.4 5.44 60.2 5.60 60.2 6.25 60.2 6.39 60.2 6.57
-4.0 -4.4 63.5 4.74 63.5 5.07 63.5 5.57 63.3
5.74 63.1 5.90 63.1 6.55 63.1 6.68 63.1 6.87
0.0 -0.4 67.2 5.11 67.2 5.44 67.2 5.94 67.0 6.10 66.8 6.27 66.8 6.91 66.8 7.05 66.8 7.24
5.0 4.5 71.8 5.57 71.8 5.90 71.8 6.40 71.6 6.56 71.3 6.73 71.3 7.37 71.3 7.51 71.3 7.70
10.0 9.0 76.4 6.03 76.4 6.36 76.4 6.86 76.1 7.02 75.9 7.19 75.9 7.83 75.9 7.97 75.9 8.16
15.0 14.0 80.9 6.48 80.9 6.81 80.9 7.31 80.6 7.47 80.4 7.64 80.4 8.28 80.4 8.42 80.4 8.61
20.0 19.0 85.6 6.95 85.6 7.28 85.6 7.78 85.3 8.06 85.0 8.34 85.0 8.09 85.0 7.98 85.0 7.84
25.0 23.0 90.2 7.41 90.2 7.74 90.2 8.24 89.9 8.09 89.6 7.94 89.1 7.73 88.0 7.62 86.6 7.48
30.0 28.0 94.7 8.30 94.7 8.20 94.7 8.06 94.4 7.80 94.2 7.55 91.9 7.36 87.6 7.26 81.9 7.12
35.0 32.0 99.3 8.31 99.3 8.02 99.3 7.57 98.4 7.36 97.4 7.15 92.9 6.99 87.2 6.89 79.7 6.76
40.0 36.0 103.9 7.60 103.9 7.40 103.9 7.09 101.3 6.92 98.6 6.76 92.9 6.62 87.2 6.53 79.7 6.40
45.0 41.0 108.0 6.92 107.3 6.80 106.2 6.61 102.4 6.49 98.6 6.36 92.9 6.25 87.2 6.16 79.7 6.04
47.0 43.0 108.0 6.74 107.3 6.62 106.2 6.44 102.4 6.31 98.6 6.19 92.9 6.09 87.2 6.00 79.7 5.88
50.0 46.0 108.0 6.49 107.3 6.37 106.2 6.20 102.4 6.08 98.6 5.96 92.9 5.86 87.2 5.78 79.7 5.66
55.0 51.0 108.0 6.09 107.3 5.98 106.2 5.82 102.4 5.71 98.6 5.60 92.9 5.50 87.2 5.42 79.7 5.31
60.0 56.0 108.0 5.66 107.3 5.56 106.2 5.41 102.4 5.31 98.6 5.20 92.9 5.12 87.2 5.04 79.7 4.94
110%
-12.6 -13.0 55.3 4.55 55.3 4.77 55.3 5.11 55.1 5.40 54.9 5.69 54.9 6.00 54.9 6.32 54.9 6.74
-7.0 -7.6 60.2 5.05 60.2 5.27 60.2 5.60 60.0 5.89 59.8 6.18 59.8 6.50 59.8 6.81 59.8 7.24
-4.0 -4.4 63.2 5.35 63.2 5.57 63.2 5.90 63.0 6.19 62.8 6.48 62.8 6.79 62.8 7.11 62.8 7.54
0.0 -0.4 66.8 5.72 66.8 5.94 66.8 6.27 66.6 6.56 66.4 6.85 66.4 7.16 66.4 7.48 66.4 7.90
5.0 4.5 71.4 6.18 71.4 6.40 71.4 6.73 71.2 7.02 71.0 7.31 71.0 7.62 71.0 7.94 71.0 8.36
10.0 9.0 76.0 6.64 76.0 6.86 76.0 7.19 75.7 7.48 75.5 7.77 75.5 8.08 75.5 8.40 75.5 8.82
15.0 14.0 80.4 7.09 80.4 7.31 80.4 7.64 80.2 7.93 79.9 8.22 79.9 8.26 79.8 8.00 79.7 7.65
20.0 19.0 85.1 7.56 85.1 7.78 85.1 8.11 84.8 8.11 84.6 8.11
82.6 7.86 78.9 7.62 74.0 7.29
25.0 23.0 89.7 8.27 89.7 8.24 89.7 8.18 88.8 7.94 88.0 7.70 83.3 7.47 78.6 7.24 72.3 6.94
30.0 28.0 94.2 8.20 94.2 7.99 94.2 7.68 91.4 7.48 88.5 7.28 83.3 7.07 78.6 6.87 72.3 6.59
35.0 32.0 100.1 7.58 98.8 7.42 96.9 7.18 92.7 7.03 88.5 6.87 83.3 6.68 78.6 6.49 72.3 6.24
40.0 36.0 105.9 6.95 102.5 6.84 97.5 6.68 93.0 6.57 88.5 6.46 83.3 6.29 78.6 6.12 72.3 5.89
45.0 41.0 106.9 6.34 103.1 6.28 97.5 6.19 93.0 6.11 88.5 6.04 83.3 5.89 78.6 5.74 72.3 5.54
47.0 43.0 106.9 6.18 103.1 6.11 97.5 6.02 93.0 5.95 88.5 5.88 83.3 5.74 78.6 5.59 72.3 5.39
50.0 46.0 106.9 5.95 103.1 5.89 97.5 5.80 93.0 5.73 88.5 5.67 83.3 5.53 78.6 5.38 72.3 5.19
55.0 51.0 106.9 5.58 103.1 5.53 97.5 5.44 93.0 5.38 88.5 5.32 83.3 5.19 78.6 5.05 72.3 4.87
60.0 56.0 106.9 5.19 103.1 5.14 97.5 5.06 93.0 5.00 88.5 4.95 83.3 4.82 78.6 4.70 72.3 4.53
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and
outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
HEATING CAPACITY DATA
72,000 Btu/h 208-230V / 460V Outdoor Units
ARUM072BTE5 / ARUM072DTE5
