160 | CORRECTION FACTORS
MULTI V 5 Outdoor Unit Performance Data Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
Equivalent Length (ELF)
1
Elevation
Differences
(ft.)
25 33 66 98 131 164 197 230 262 295 328 361 394 427 459 492 525 558 591 623 656 689 738
HU—Indoor units above heat pump unit (ft.)
0
1.0 0.99 0.97 0.95 0.94 0.92 0.90 0.89 0.88 0.86 0.85 0.84 0.83 0.82 0.81 0.81 0.80 0.79 0.78 0.77 0.77 0.76 0.75
25
0.99 0.99 0.97 0.95 0.94 0.92 0.91 0.89 0.88 0.87 0.85 0.84 0.83 0.82 0.81 0.81 0.80 0.79 0.78 0.77 0.77 0.76 0.75
33
- 0.99 0.97 0.96 0.94 0.92 0.91 0.89 0.88 0.87 0.85 0.84 0.83 0.82 0.81 0.81 0.80 0.79 0.78 0.77 0.77 0.76 0.75
66
- - 0.97 0.96 0.94 0.92 0.91 0.89 0.88 0.87 0.86 0.84 0.83 0.82 0.82 0.81 0.80 0.79 0.78 0.78 0.77 0.76 0.75
98
- - - 0.96 0.94 0.92 0.91 0.90 0.88 0.87 0.86 0.85 0.84 0.83 0.82 0.81 0.80 0.79 0.78 0.78 0.77 0.76 0.75
131
- - - - 0.94 0.93 0.91 0.90 0.88 0.87 0.86 0.85 0.84 0.83 0.82 0.81 0.80 0.79 0.78 0.78 0.77 0.76 0.75
164
- - - - - 0.93 0.91 0.90 0.88 0.88 0.86 0.85 0.84 0.83 0.82 0.81 0.80 0.79 0.79 0.78 0.77 0.76 0.75
197
------0.910.900.890.880.860.850.840.830.820.810.800.790.790.780.770.760.75
230
-------0.900.890.880.860.850.840.830.820.810.800.790.790.780.770.760.76
263
--------0.890.880.860.850.840.830.820.810.800.800.790.780.770.770.76
295
---------0.880.860.850.840.830.820.810.800.800.800.780.770.770.76
328
----------0.860.850.840.830.820.810.800.800.800.780.770.770.76
361
-----------0.850.840.830.820.810.800.800.800.780.770.770.76
HL—Indoor units below heat pump unit (ft.)
0
1.0 0.99 0.97 0.96 0.94 0.93 0.91 0.90 0.89 0.87 0.86 0.85 0.84 0.83 0.82 0.81 0.80 0.80 0.79 0.78 0.77 0.77 0.76
25
1.0 0.99 0.97 0.96 0.94 0.93 0.91 0.90 0.89 0.88 0.86 0.85 0.84 0.83 0.82 0.81 0.81 0.80 0.79 0.78 0.77 0.77 0.76
33
- 0.99 0.98 0.96 0.94 0.93 0.91 0.90 0.89 0.88 0.86 0.85 0.84 0.83 0.82 0.81 0.81 0.80 0.79 0.78 0.77 0.77 0.76
66
- - 0.98 0.96 0.94 0.93 0.91 0.90 0.89 0.88 0.87 0.86 0.84 0.83 0.82 0.82 0.81 0.80 0.79 0.78 0.78 0.77 0.76
98
- - - 0.96 0.95 0.93 0.92 0.90 0.89 0.88 0.87 0.86 0.84 0.83 0.83 0.82 0.81 0.80 0.79 0.78 0.78 0.77 0.76
131
- - - - 0.95 0.93 0.92 0.90 0.89 0.88 0.87 0.86 0.85 0.84 0.83 0.82 0.81 0.80 0.79 0.78 0.78 0.77 0.76
164
- - - - - 0.93 0.92 0.91 0.89 0.88 0.87 0.86 0.85 0.84 0.83 0.82 0.81 0.80 0.79 0.78 0.78 0.77 0.76
197
------0.920.910.890.880.870.860.850.840.830.820.810.800.790.790.780.770.76
230
-------0.910.890.880.870.860.850.840.830.820.810.800.790.790.780.770.76
263
--------0.900.880.870.860.850.840.830.820.810.800.790.790.780.770.76
295
---------0.880.870.860.850.840.830.820.810.800.800.790.780.770.76
328
----------0.870.860.850.840.830.820.810.800.800.790.780.760.76
361
-----------0.860.850.840.830.820.810.800.800.790.780.760.76
Heating Correction Factor for 360BTE5 / 360DTE5 to 504TE5 / 504DTE5 models is 1.0 for all equivalent lengths and elevation differences.
Table 4: ARUM Outdoor Unit Cooling Correction Factors (360BTE5 / 360DTE5 to 504BTE5 / 504DTE5).
1
ELF = Equivalent Pipe Length in Feet—Sum of the actual pipe length plus allocations for pressure drop through elbows, valves, and other fittings in equivalent length.
CORRECTION FACTORS
The correction factors shown below are calculated in the LATS software programs.

LG Multi V 5 Specifications

General

Type	VRF (Variable Refrigerant Flow)
Refrigerant	R410A
Compressor Type	Inverter Scroll Compressor
Outdoor Unit Fan Type	Axial Fan
Cooling Capacity	22.4 kW to 270 kW
Energy Efficiency	High
Operating Range	Cooling: -5°C to 48°C
Power Supply	380-415V, 50/60Hz
Heat Exchanger Type	Microchannel
Control Type	Centralized Control
Indoor Unit Options	Cassette, Wall Mounted, Ducted
Heat Recovery	Available
Warranty	Varies by region (typically 5 years compressor, 1-2 years parts)
