PERFORMANCE DATA | 35
Performance Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
COOLING CAPACITY DATA
216,000 Btu/h 208-230V / 460V Outdoor Units
ARUM216BTE5 / ARUM216DTE5
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the Low Ambient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%)
Outdoor
air temp.
(°F DB)
Indoor Air Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
130%
-9.9 196.4 4.92 233.3 5.97 271.2 7.09 281.2 7.65 285.2 8.25 295.1 9.46 302.1 9.77
-5 196.4 5.19 233.3 6.30 271.2 7.48 281.2 8.07 285.2 8.71 295.1 9.98 302.1 10.31
0 196.4 5.40 233.3 6.56 271.2 7.78 281.2 8.40 285.2 9.06 295.1 10.38 302.1 10.73
5 196.4 5.60 233.3 6.80 271.2 8.07 281.2 8.70 285.2 9.39 295.1 10.76 302.1 11.12
10 196.4 5.76 233.3 6.99 271.2 8.30 281.2 8.95 285.2 9.66 295.1 11.07 302.1 11.44
14 196.4 5.97 233.3 7.24 271.2 8.60 281.2 9.28 285.2 10.01 295.1 11.47 302.1 11.85
20 196.4 6.07 233.3 7.36 271.2 8.72 281.2 9.42 285.2 10.15 295.1 11.63 302.1 12.03
25 196.4 6.16 233.3 7.46 271.2 8.83 281.2 9.54 285.2 10.26 295.1 11.76 302.1 12.17
30 196.4 6.24 233.3 7.55 271.2 8.93 281.2 9.66 285.2 10.38 295.1 11.90 302.1 12.31
35 196.4 6.31 233.3 7.65 271.2 9.04 281.2 9.76 285.2 10.51 295.1 12.04 302.1 12.46
40 196.4 6.39 233.3 7.73 271.2 9.15 281.2 9.89 285.2 10.63 295.1 12.18 302.1 12.61
45 196.4 6.46 233.3 7.81 271.2 9.25 281.2 9.99 285.2 10.73 295.1 12.31 302.1 12.73
50 196.4 6.52 233.3 7.89 271.2 9.33 281.2 10.09 285.2 10.85 295.1 12.43 302.1 12.86
55 196.4 6.63 233.3 8.04 271.2 9.51 277.2 10.31 281.2 11.06 291.0 12.65 298.1 12.95
60 196.4 6.85 233.3 8.32 267.2 9.91 271.0 10.70 274.2 11.49 284.0 13.04 291.0 13.10
65 196.4 6.99 233.3 8.50 263.2 10.09 267.2 10.92 270.2 11.71 280.0 13.48 287.0 13.58
70 196.4 6.73 233.3 8.17 258.2 10.06 261.2 11.06 265.2 12.14 274.9 13.49 282.0 13.62
75 196.4 6.89 233.3 8.71 254.3 10.76 257.2 11.87 261.2 13.02 270.9 14.13 277.9 14.23
80 196.4 7.84 233.3 9.92 247.3 12.31 250.3 13.59 254.3 14.93 263.8 15.34 270.9 15.47
85 196.4 8.34 233.3 10.59 243.3 13.15 247.3 14.50 250.3 15.84 259.8 15.98 266.9 16.11
90 196.4 9.45 229.3 12.04 236.3 14.93 239.3 16.51 243.3 17.09 252.8 17.22 259.8 17.39
95 198.5 10.02 227.7 12.81 234.8 15.94 238.8 17.62 241.8 17.69 251.4 17.86 258.5 18.03
100 198.5 10.85 223.7 13.86 230.8 17.28 234.8 18.55 237.8 18.65 248.3 18.82 255.5 18.99
105 198.5 12.23 217.7 15.68 224.7 19.49 228.2 19.94 231.7 20.05 239.7 20.23
243.2 20.42
110 198.5 13.73 208.7 17.67 217.4 21.26 218.1 21.37 221.3 21.44 226.0 21.65 226.8 21.85
115 197.5 15.89 201.1 20.32 201.1 22.41 201.1 22.41 201.1 22.41 204.0 22.45 204.9 22.49
118 171.7 13.46 174.9 17.22 175.1 18.85 175.1 19.02 175.1 19.02 177.6 19.05 176.9 19.09
122 137.2 10.21 140.2 13.09 139.6 14.35 139.9 14.38 140.2 14.40 142.6 14.44 142.4 14.50
120%
-9.9 178.7 4.64 213.3 5.62 247.9 6.66 265.6 7.18 277.5 7.74 290.1 8.88 296.1 9.17
-5 178.7 4.89 213.3 5.93 247.9 7.02 265.6 7.57 277.5 8.17 290.1 9.36 296.1 9.68
0 178.7 5.09 213.3 6.17 247.9 7.31 265.6 7.88 277.5 8.50 290.1 9.74 296.1 10.07
5 178.7 5.28 213.3 6.40 247.9 7.57 265.6 8.17 277.5 8.81 290.1 10.10 296.1 10.44
10 178.7 5.43 213.3 6.58 247.9 7.79 265.6 8.40 277.5 9.06 290.1 10.39 296.1 10.74
14 178.7 5.63 213.3 6.82 247.9 8.07 265.6 8.71 277.5 9.39 290.1 10.76 296.1 11.12
20 178.7 5.71 213.3 6.92 247.9 8.19 265.6 8.84 277.5 9.52 290.1 10.92 296.1 11.29
25 178.7 5.79 213.3 7.01 247.9 8.29 265.6 8.95 277.5 9.63 290.1 11.04 296.1 11.42
30 178.7 5.86 213.3 7.09 247.9 8.38 265.6 9.06 277.5 9.74 290.1 11.17 296.1 11.56
35 178.7 5.94 213.3 7.17 247.9 8.49 265.6 9.18 277.5 9.86 290.1 11.30 296.1 11.70
40 178.7 6.01 213.3 7.27 247.9 8.60 265.6 9.29 277.5 9.99 290.1 11.45 296.1 11.85
45 178.7 6.08 213.3 7.35 247.9 8.69 265.6 9.40 277.5 10.10 290.1 11.57 296.1 11.98
50 178.7 6.14 213.3 7.43 247.9 8.79 265.6 9.50 277.5 10.21 290.1 11.71 296.1 12.11
55 178.7 6.24 213.3 7.57 247.9 8.96 265.6 9.71 274.5 10.42 286.1 11.91 293.1 12.20
60 178.7 6.45 213.3 7.84 247.9 9.33 263.7 10.08 266.6 10.82 279.0 12.28 285.1 12.50
65 178.7 6.58 213.3 8.01 247.9 9.50 259.7 10.28 263.7 11.03 275.0 12.69 282.0 12.79
70 178.7 6.46 213.3 7.85 247.9 9.65 254.8 10.62 257.7 11.66 269.9 12.95 276.0 13.08
75 178.7 6.62 213.3 8.36 247.9 10.33 250.8 11.40 254.8 12.50 265.9 13.56 273.0 13.66
80 178.7 7.52 213.3 9.52 241.0 11.82 243.9 13.04 246.9 14.34 258.9 14.72 264.9 14.85
85 178.7 8.01 213.3 10.17 237.0 12.62 240.0 13.92 243.9 15.21 254.8 15.34 261.9 15.47
90 178.7 9.07 213.3 11.56 230.1 14.34 233.1 15.85 236.0 16.40 247.8 16.53 253.8 16.69
95 180.6 9.62 215.6 12.30 228.5 15.30 231.5 16.92 235.5 16.98 246.3 17.14 253.5 17.31
100 180.6 10.41 215.6 13.30 224.5 16.59
228.5 17.81 231.5 17.90 243.3 18.07 249.4 18.23
105 180.6 11.73 212.1 15.06 218.6 18.72 222.1 19.14 225.0 19.25 236.2 19.42 240.1 19.60
110 180.6 13.18 206.7 16.96 213.4 20.41 214.1 20.51 217.2 20.58 224.0 20.78 224.9 20.98
115 175.6 15.25 199.1 19.51 199.1 21.52 199.1 21.52 199.1 21.52 204.0 21.56 205.0 21.59
118 156.8 13.46 173.2 16.53 173.4 18.09 173.4 18.26 173.4 18.26 177.7 18.29 176.9 18.32
122 125.3 10.21 138.9 12.57 138.2 13.77 138.5 13.81 138.9 13.82 142.7 13.86 142.4 13.92
