TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the Low Ambient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%)
Outdoor
air temp.
(°F DB)
Indoor Air Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
130%
-9.9 152.8 3.92 181.5 4.75 210.9 5.64 218.7 6.09 221.8 6.57 229.5 7.53 235.0 7.78
-5 152.8 4.13 181.5 5.01 210.9 5.95 218.7 6.42 221.8 6.93 229.5 7.94 235.0 8.21
0 152.8 4.30 181.5 5.22 210.9 6.19 218.7 6.68 221.8 7.21 229.5 8.26 235.0 8.54
5 152.8 4.46 181.5 5.41 210.9 6.42 218.7 6.93 221.8 7.47 229.5 8.56 235.0 8.85
10 152.8 4.58 181.5 5.56 210.9 6.60 218.7 7.12 221.8 7.69 229.5 8.81 235.0 9.10
14 152.8 4.75 181.5 5.76 210.9 6.84 218.7 7.38 221.8 7.96 229.5 9.13 235.0 9.43
20 152.8 4.83 181.5 5.86 210.9 6.94 218.7 7.50 221.8 8.07 229.5 9.26 235.0 9.57
25 152.8 4.90 181.5 5.93 210.9 7.02 218.7 7.59 221.8 8.17 229.5 9.36 235.0 9.68
30 152.8 4.97 181.5 6.01 210.9 7.11 218.7 7.68 221.8 8.26 229.5 9.47 235.0 9.80
35 152.8 5.02 181.5 6.09 210.9 7.19 218.7 7.77 221.8 8.36 229.5 9.58 235.0 9.91
40 152.8 5.09 181.5 6.15 210.9 7.28 218.7 7.87 221.8 8.46 229.5 9.69 235.0 10.03
45 152.8 5.14 181.5 6.22 210.9 7.36 218.7 7.95 221.8 8.54 229.5 9.80 235.0 10.13
50 152.8 5.19 181.5 6.28 210.9 7.43 218.7 8.03 221.8 8.63 229.5 9.89 235.0 10.24
55 152.8 5.28 181.5 6.39 210.9 7.57 215.6 8.20 218.7 8.80 226.4 10.06 231.8 10.31
60 152.8 5.45 181.5 6.62 207.8 7.89 210.8 8.52 213.3 9.15 220.9 10.38 226.4 10.42
65 152.8 5.56 181.5 6.77 204.7 8.03 207.8 8.69 210.2 9.32 217.7 10.72 223.2 10.81
70 152.8 5.35 181.5 6.50 200.9 8.00 203.2 8.80 206.3 9.66 213.8 10.73 219.3 10.84
75 152.8 5.49 181.5 6.93 197.8 8.56 200.1 9.45 203.2 10.36 210.7 11.24 216.2 11.32
80 152.8 6.24 181.5 7.89 192.3 9.79 194.7 10.81 197.8 11.88 205.2 12.20 210.7 12.31
85 152.8 6.64 181.5 8.43 189.2 10.46 192.3 11.53 194.7 12.60 202.1 12.71 207.6 12.82
90 152.8 7.52 178.4 9.58 183.8 11.88 186.1 13.14 189.2 13.59 196.6 13.70 202.1 13.84
95 154.4 7.97 177.1 10.20 182.6 12.68 185.7 14.02 188.1 14.08 195.5 14.21 201.1 14.34
100 154.4 8.63 174.0 11.03 179.5 13.75 182.6 14.76 185.0 14.84 193.1 14.98 198.7 15.11
105 154.4 9.73 169.3 12.48 174.8 15.51 177.5 15.87 180.2 15.95 186.4 16.10
189.1 16.25
110 154.4 10.93 162.3 14.06 169.1 16.92 169.6 17.00 172.1 17.06 175.7 17.22 176.4 17.39
115 153.6 12.64 156.4 16.17 156.4 17.83 156.4 17.83 156.4 17.83 158.7 17.87 159.4 17.90
118 133.6 10.71 136.0 13.70 136.2 15.00 136.2 15.13 136.2 15.13 138.2 15.16 137.6 15.19
122 106.7 8.13 109.1 10.42 108.5 11.42 108.8 11.44 109.1 11.46 110.9 11.49 110.8 11.54
120%
-9.9 139.0 3.69 165.9 4.47 192.8 5.30 206.6 5.71 215.8 6.16 225.6 7.06 230.3 7.30
-5 139.0 3.89 165.9 4.72 192.8 5.59 206.6 6.03 215.8 6.50 225.6 7.45 230.3 7.70
0 139.0 4.05 165.9 4.91 192.8 5.81 206.6 6.27 215.8 6.76 225.6 7.75 230.3 8.01
5 139.0 4.20 165.9 5.09 192.8 6.03 206.6 6.50 215.8 7.01 225.6 8.03 230.3 8.30
10 139.0 4.32 165.9 5.24 192.8 6.20 206.6 6.69 215.8 7.21 225.6 8.27 230.3 8.54
14 139.0 4.48 165.9 5.43 192.8 6.42 206.6 6.93 215.8 7.47 225.6 8.56 230.3 8.85
20 139.0 4.55 165.9 5.51 192.8 6.52 206.6 7.03 215.8 7.58 225.6 8.69 230.3 8.98
25 139.0 4.60 165.9 5.57 192.8 6.59 206.6 7.12 215.8 7.67 225.6 8.79 230.3 9.09
30 139.0 4.66 165.9 5.64 192.8 6.67 206.6 7.21 215.8 7.75 225.6 8.89 230.3 9.20
35 139.0 4.72 165.9 5.71 192.8 6.75 206.6 7.31 215.8 7.85 225.6 8.99 230.3 9.31
40 139.0 4.78 165.9 5.78 192.8 6.84 206.6 7.39 215.8 7.95 225.6 9.11 230.3 9.43
45 139.0 4.84 165.9 5.84 192.8 6.92 206.6 7.48 215.8 8.04 225.6 9.21 230.3 9.54
50 139.0 4.89 165.9 5.91 192.8 6.99 206.6 7.56 215.8 8.13 225.6 9.32 230.3 9.64
55 139.0 4.97 165.9 6.02 192.8 7.13 206.6 7.72 213.5 8.29 222.5 9.48 228.0 9.71
60 139.0 5.13 165.9 6.24 192.8 7.43 205.1 8.02 207.4 8.61 217.0 9.77 221.7 9.95
65 139.0 5.24 165.9 6.37 192.8 7.56 202.0 8.18 205.1 8.78 213.9 10.10 219.4 10.18
70 139.0 5.14 165.9 6.24 192.8 7.68 198.2 8.45 200.5 9.27 210.0 10.30 214.7 10.40
75 139.0 5.27 165.9 6.65 192.8 8.22 195.1 9.07 198.2 9.94 206.8 10.79 212.3 10.87
80 139.0 5.99 165.9 7.58 187.4 9.40 189.7 10.38 192.0 11.41 201.3 11.72 206.0 11.82
85 139.0 6.37 165.9 8.09 184.3 10.05 186.6 11.07 189.7 12.10 198.2 12.20 203.7 12.31
90 139.0 7.22 165.9 9.20 179.0 11.41 181.3 12.61 183.6 13.05 192.7 13.15 197.4 13.28
95 140.5 7.66 167.7 9.79 177.7 12.18 180.1 13.46 183.2 13.51 191.6 13.64 197.1 13.77
100 140.5 8.29 167.7 10.59 174.6 13.20
177.7 14.17 180.1 14.25 189.2 14.38 194.0 14.51
105 140.5 9.34 165.0 11.99 170.0 14.90 172.7 15.23 175.0 15.32 183.7 15.45 186.8 15.59
110 140.5 10.49 160.8 13.50 166.0 16.24 166.5 16.32 169.0 16.37 174.2 16.53 174.9 16.69
115 136.6 12.14 154.9 15.53 154.9 17.12 154.9 17.12 154.9 17.12 158.7 17.15 159.4 17.18
118 122.0 10.71 134.7 13.15 134.9 14.40 134.9 14.53 134.9 14.53 138.2 14.55 137.6 14.58
122 97.5 8.13 108.0 10.00 107.5 10.96 107.8 10.99 108.0 11.00 111.0 11.03 110.8 11.08
COOLING CAPACITY DATA
168,000 Btu/h 208-230V / 460V Outdoor Units
ARUM168BTE5 / ARUM168DTE5
