LG Multi V 5

PERFORMANCE DATA | 11
Performance Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the Low Ambient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%)
Outdoor
air temp.
(°F DB)
Indoor Air Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
110%
-9.9 73.6 1.48 87.8 1.79 102.0 2.12 109.1 2.30 116.2 2.46 128.0 2.81 130.7 2.91
-5 73.6 1.56 87.8 1.88 102.0 2.23 109.1 2.42 116.2 2.59 128.0 2.96 130.7 3.07
0 73.6 1.63 87.8 1.96 102.0 2.32 109.1 2.52 116.2 2.70 128.0 3.08 130.7 3.19
5 73.6 1.68 87.8 2.03 102.0 2.41 109.1 2.61 116.2 2.80 128.0 3.19 130.7 3.31
10 73.6 1.73 87.8 2.09 102.0 2.48 109.1 2.69 116.2 2.88 128.0 3.28 130.7 3.41
14 73.6 1.80 87.8 2.17 102.0 2.57 109.1 2.78 116.2 2.98 128.0 3.40 130.7 3.53
20 73.6 1.82 87.8 2.20 102.0 2.61 109.1 2.82 116.2 3.03 128.0 3.46 130.7 3.58
25 73.6 1.84 87.8 2.23 102.0 2.64 109.1 2.85 116.2 3.07 128.0 3.51 130.7 3.63
30 73.6 1.87 87.8 2.26 102.0 2.67 109.1 2.89 116.2 3.10 128.0 3.56 130.7 3.68
35 73.6 1.89 87.8 2.29 102.0 2.71 109.1 2.93 116.2 3.15 128.0 3.61 130.7 3.74
40 73.6 1.92 87.8 2.32 102.0 2.75 109.1 2.97 116.2 3.19 128.0 3.66 130.7 3.78
45 73.6 1.95 87.8 2.36 102.0 2.79 109.1 3.02 116.2 3.25 128.0 3.72 130.7 3.85
50 73.6 1.98 87.8 2.40 102.0 2.84 109.1 3.07 116.2 3.30 128.0 3.78 130.7 3.91
55 73.6 2.02 87.8 2.44 102.0 2.89 109.1 3.13 116.2 3.36 126.2 3.85 128.9 3.94
60 73.6 2.08 87.8 2.53 102.0 3.01 109.1 3.25 116.2 3.50 123.1 3.97 125.8 4.00
65 73.6 2.13 87.8 2.59 102.0 3.07 109.1 3.32 116.2 3.56 121.2 4.10 124.0 4.13
70 73.6 2.15 87.8 2.61 102.0 3.21 109.1 3.53 114.0 3.88 119.0 4.31 121.7 4.35
75 73.6 2.20 87.8 2.78 102.0 3.44 109.1 3.79 112.2 4.15 117.2 4.51 119.9 4.54
80 72.9 2.50 86.9 3.17 101.0 3.93 106.7 4.34 108.0 4.77 112.8 4.90 115.5 4.94
85 72.9 2.66 86.9 3.38 101.0 4.20 104.9 4.63 106.2 5.06 111.0 5.10 113.7 5.14
90 72.9 3.02 86.9 3.84 100.5 4.77 101.8 5.27 103.2 5.45 107.9 5.50 110.6 5.55
95 72.9 3.20 86.9 4.09 98.8 5.09 100.1 5.63 101.4 5.65 106.1 5.70 108.8 5.75
100 72.9 3.46 86.9 4.42 97.5 5.52 98.8 5.92 100.1 5.95 104.8 6.01 107.5 6.06
105 72.9 3.90 86.9 5.00 94.4 6.22 95.7 6.37 97.0 6.40 101.7 6.46
104.3 6.52
110 72.9 4.38 86.9 5.64 91.5 6.79 91.8 6.82 93.1 6.84 96.0 6.91 96.4 6.98
115 72.9 5.07 86.9 6.49 87.6 7.15 87.6 7.15 88.0 7.15 89.8 7.17 90.2 7.18
118 70.4 4.62 75.6 5.50 76.3 6.02 76.3 6.07 76.6 6.07 78.2 6.08 77.8 6.09
122 56.3 3.51 60.6 4.18 60.8 4.58 60.9 4.59 61.4 4.60 62.8 4.61 62.6 4.63
100%
-9.9 64.7 1.30 77.1 1.57 89.6 1.86 96.0 2.03 105.5 2.20 118.3 2.53 124.9 2.64
-5 64.7 1.37 77.1 1.66 89.6 1.97 96.0 2.14 105.5 2.32 118.3 2.67 124.9 2.78
0 64.7 1.43 77.1 1.73 89.6 2.04 96.0 2.23 105.5 2.41 118.3 2.78 124.9 2.90
5 64.7 1.48 77.1 1.79 89.6 2.12 96.0 2.31 105.5 2.50 118.3 2.88 124.9 3.00
10 64.7 1.52 77.1 1.84 89.6 2.18 96.0 2.38 105.5 2.57 118.3 2.97 124.9 3.09
14 64.7 1.58 77.1 1.91 89.6 2.26 96.0 2.46 105.5 2.66 118.3 3.07 124.9 3.20
20 64.7 1.63 77.1 1.97 89.6 2.33 96.0 2.53 105.5 2.75 118.3 3.16 124.9 3.29
25 64.7 1.67 77.1 2.02 89.6 2.39 96.0 2.59 105.5 2.82 118.3 3.24 124.9 3.37
30 64.7 1.71 77.1 2.07 89.6 2.45 96.0 2.65 105.5 2.89 118.3 3.31 124.9 3.44
35 64.7 1.74 77.1 2.11 89.6 2.49 96.0 2.69 105.5 2.94 118.3 3.37 124.9 3.50
40 64.7 1.77 77.1 2.14 89.6 2.53 96.0 2.73 105.5 2.98 118.3 3.42 124.9 3.56
45 64.7 1.81 77.1 2.19 89.6 2.58 96.0 2.79 105.5 3.04 118.3 3.49 124.9 3.63
50 64.7 1.84 77.1 2.23 89.6 2.63 96.0 2.85 105.5 3.11 118.3 3.56 124.9 3.70
55 64.7 1.87 77.1 2.27 89.6 2.69 96.0 2.91 105.5 3.17 118.3 3.62 123.6 3.76
60 64.7 1.93 77.1 2.35 89.6 2.80 96.0 3.02 105.5 3.29 117.9 3.74 120.1 3.83
65 64.7 1.97 77.1 2.40 89.6 2.85 96.0 3.08 105.5 3.36 116.1 3.86 118.7 3.94
70 64.7 2.03 77.1 2.47 89.6 3.04 96.0 3.35 105.5 3.73 113.9 4.14 116.1 4.21
75 64.7 2.09 77.1 2.63 89.6 3.25 96.0 3.59 105.5 4.00 112.1 4.34 114.8 4.39
80 64.7 2.37 77.1 3.00 89.6 3.72 96.0 4.11 105.5 4.58 109.0 4.71 111.2 4.77
85 64.7 2.52 77.1 3.20 89.6 3.98 96.0 4.38 105.1 4.86 107.3 4.90 109.9 4.97
90 64.7 2.86 77.1 3.64 89.6 4.52 96.0 4.99 101.5 5.24 104.2 5.29 106.4 5.36
95 64.7 3.03 77.1 3.88 89.6 4.82 96.0 5.33 100.2 5.43 102.4 5.48 105.1 5.56
100 64.7 3.27 77.1 4.18 89.6 5.21
94.3 5.60 98.5 5.71 101.1 5.76 103.3 5.85
105 64.7 3.68 77.1 4.71 89.1 5.86 91.7 6.00 95.5 6.12 98.0 6.17 100.4 6.26
110 64.7 4.11 77.1 5.29 88.1 6.36 90.0 6.40 91.9 6.51 93.3 6.58 95.0 6.67
115 64.7 4.72 77.1 6.04 83.8 6.66 86.4 6.66 88.6 6.76 89.4 6.77 89.8 6.82
118 64.7 4.76 67.7 5.67 73.0 5.60 75.2 5.65 77.1 5.74 77.8 5.75 77.5 5.79
122 55.4 4.31 54.3 4.31 58.2 4.27 60.1 4.28 61.8 4.34 62.5 4.36 62.4 4.40
COOLING CAPACITY DATA
96,000 Btu/h 208-230V / 460V Outdoor Units
ARUM096BTE5 / ARUM096DTE5
