COOLING CAPACITY DATA
240,000 Btu/h 208-230V / 460V Outdoor Units
ARUM241BTE5 / ARUM241DTE5
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the Low Ambient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%)
Outdoor
air temp.
(°F DB)
Indoor Air Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
110%
-9.9 184.1 4.67 219.5 5.63 255.0 6.67 272.8 7.23 290.5 7.75 320.1 8.84 326.9 9.17
-5 184.1 4.92 219.5 5.94 255.0 7.04 272.8 7.63 290.5 8.18 320.1 9.33 326.9 9.68
0 184.1 5.12 219.5 6.18 255.0 7.32 272.8 7.94 290.5 8.51 320.1 9.71 326.9 10.07
5 184.1 5.31 219.5 6.41 255.0 7.59 272.8 8.23 290.5 8.82 320.1 10.06 326.9 10.44
10 184.1 5.46 219.5 6.59 255.0 7.81 272.8 8.47 290.5 9.07 320.1 10.35 326.9 10.74
14 184.1 5.66 219.5 6.83 255.0 8.09 272.8 8.77 290.5 9.40 320.1 10.73 326.9 11.13
20 184.1 5.74 219.5 6.94 255.0 8.21 272.8 8.90 290.5 9.54 320.1 10.91 326.9 11.30
25 184.1 5.81 219.5 7.03 255.0 8.32 272.8 9.00 290.5 9.66 320.1 11.06 326.9 11.44
30 184.1 5.88 219.5 7.12 255.0 8.42 272.8 9.10 290.5 9.78 320.1 11.21 326.9 11.59
35 184.1 5.97 219.5 7.22 255.0 8.53 272.8 9.23 290.5 9.93 320.1 11.38 326.9 11.78
40 184.1 6.05 219.5 7.32 255.0 8.66 272.8 9.36 290.5 10.06 320.1 11.53 326.9 11.92
45 184.1 6.15 219.5 7.43 255.0 8.80 272.8 9.51 290.5 10.23 320.1 11.73 326.9 12.12
50 184.1 6.25 219.5 7.56 255.0 8.95 272.8 9.67 290.5 10.40 320.1 11.92 326.9 12.31
55 184.1 6.35 219.5 7.70 255.0 9.12 272.8 9.88 290.5 10.60 315.5 12.12 322.3 12.43
60 184.1 6.56 219.5 7.98 255.0 9.50 272.8 10.26 290.5 11.02 307.6 12.50 314.4 12.61
65 184.1 6.70 219.5 8.15 255.0 9.67 272.8 10.46 290.5 11.22 303.1 12.92 309.9 13.02
70 184.1 6.77 219.5 8.22 255.0 10.12 272.8 11.13 285.0 12.22 297.4 13.57 304.2 13.70
75 184.1 6.94 219.5 8.76 255.0 10.83 272.8 11.95 280.5 13.10 292.9 14.21 299.7 14.31
80 182.2 7.88 217.3 9.98 252.4 12.39 266.7 13.67 270.0 15.02 282.1 15.43 288.8 15.57
85 182.2 8.39 217.3 10.66 252.4 13.23 262.3 14.58 265.6 15.94 277.6 16.07 284.3 16.21
90 182.2 9.51 217.3 12.11 251.3 15.02 254.6 16.61 257.9 17.19 269.8 17.33 276.5 17.49
95 182.2 10.08 217.3 12.89 246.9 16.04 250.2 17.73 253.5 17.80 265.3 17.97 272.0 18.14
100 182.2 10.92 217.3 13.94 243.6 17.39 246.9 18.66 250.2 18.76 261.9 18.94 268.7 19.11
105 182.2 12.30 217.3 15.77 236.1 19.62 239.3 20.08 242.6 20.17 254.2 20.35
260.7 20.55
110 182.2 13.82 217.3 17.78 228.7 21.39 229.4 21.50 232.8 21.57 240.1 21.78 241.0 21.99
115 182.2 15.99 217.3 20.45 219.0 22.55 219.0 22.55 220.0 22.55 224.4 22.59 225.4 22.63
118 176.1 14.57 189.0 17.33 190.7 18.96 190.7 19.13 191.6 19.13 195.4 19.17 194.6 19.20
122 140.7 11.05 151.5 13.17 152.0 14.44 152.4 14.47 153.4 14.49 156.9 14.53 156.6 14.59
100%
-9.9 161.8 4.11 192.9 4.96 223.9 5.87 240.0 6.40 263.8 6.92 295.8 7.99 312.3 8.32
-5 161.8 4.33 192.9 5.23 223.9 6.20 240.0 6.75 263.8 7.31 295.8 8.43 312.3 8.78
0 161.8 4.51 192.9 5.44 223.9 6.45 240.0 7.02 263.8 7.60 295.8 8.77 312.3 9.13
5 161.8 4.67 192.9 5.64 223.9 6.68 240.0 7.28 263.8 7.88 295.8 9.09 312.3 9.46
10 161.8 4.81 192.9 5.80 223.9 6.87 240.0 7.49 263.8 8.10 295.8 9.35 312.3 9.74
14 161.8 4.98 192.9 6.01 223.9 7.12 240.0 7.76 263.8 8.40 295.8 9.69 312.3 10.09
20 161.8 5.14 192.9 6.20 223.9 7.35 240.0 7.98 263.8 8.66 295.8 9.97 312.3 10.38
25 161.8 5.27 192.9 6.37 223.9 7.53 240.0 8.16 263.8 8.89 295.8 10.21 312.3 10.62
30 161.8 5.40 192.9 6.53 223.9 7.72 240.0 8.35 263.8 9.11 295.8 10.44 312.3 10.86
35 161.8 5.48 192.9 6.64 223.9 7.85 240.0 8.48 263.8 9.26 295.8 10.62 312.3 11.04
40 161.8 5.57 192.9 6.74 223.9 7.97 240.0 8.62 263.8 9.40 295.8 10.78 312.3 11.21
45 161.8 5.70 192.9 6.89 223.9 8.13 240.0 8.80 263.8 9.59 295.8 11.00 312.3 11.44
50 161.8 5.80 192.9 7.02 223.9 8.30 240.0 8.98 263.8 9.80 295.8 11.23 312.3 11.67
55 161.8 5.90 192.9 7.15 223.9 8.46 240.0 9.17 263.8 9.99 295.8 11.42 309.0 11.84
60 161.8 6.09 192.9 7.41 223.9 8.82 240.0 9.52 263.8 10.38 294.7 11.78 300.2 12.06
65 161.8 6.22 192.9 7.57 223.9 8.98 240.0 9.71 263.8 10.58 290.2 12.17 296.9 12.41
70 161.8 6.41 192.9 7.79 223.9 9.59 240.0 10.55 263.8 11.75 284.7 13.05 290.2 13.28
75 161.8 6.57 192.9 8.30 223.9 10.26 240.0 11.32 263.8 12.59 280.3 13.67 286.9 13.83
80 161.8 7.47 192.9 9.46 223.9 11.73 240.0 12.95 263.8 14.45 272.6 14.84 278.1 15.04
85 161.8 7.95 192.9 10.10 223.9 12.54 240.0 13.82 262.7 15.33 268.2 15.46 274.8 15.66
90 161.8 9.01 192.9 11.48 223.9 14.24 240.0 15.74 253.8 16.53 260.4 16.66 266.0 16.91
95 161.8 9.55 192.9 12.22 223.9 15.20 240.0 16.80 250.5 17.12 256.0 17.28 262.7 17.53
100 161.8 10.32 192.9 13.18 223.9 16.44
235.7 17.64 246.2 18.00 252.7 18.17 258.4 18.42
105 161.8 11.59 192.9 14.85 222.7 18.48 229.2 18.90 238.8 19.29 245.0 19.45 251.0 19.72
110 161.8 12.96 192.9 16.67 220.1 20.06 225.1 20.16 229.7 20.53 233.3 20.73 237.6 21.03
115 161.8 14.89 192.9 19.04 209.5 21.00 216.0 21.00 221.4 21.32 223.5 21.35 224.5 21.50
118 161.8 15.02 169.2 17.86 182.4 17.66 188.1 17.82 192.8 18.09 194.6 18.12 193.8 18.24
122 138.4 13.59 135.7 13.58 145.4 13.44 150.3 13.48 154.4 13.69 156.2 13.73 156.0 13.86
