COOLING CAPACITY DATA
336,000 Btu/h 208-230V / 460V Outdoor Units
ARUM336BTE5 / ARUM336DTE5
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the Low Ambient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%)
Outdoor
air temp.
(°F DB)
Indoor Air Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
110%
-9.9 257.7 6.41 307.4 7.74 357.0 9.18 381.9 9.94 406.8 10.65 448.1 12.15 457.6 12.61
-5 257.7 6.77 307.4 8.17 357.0 9.68 381.9 10.49 406.8 11.24 448.1 12.83 457.6 13.31
0 257.7 7.04 307.4 8.49 357.0 10.07 381.9 10.91 406.8 11.69 448.1 13.34 457.6 13.84
5 257.7 7.30 307.4 8.80 357.0 10.44 381.9 11.31 406.8 12.12 448.1 13.82 457.6 14.35
10 257.7 7.51 307.4 9.06 357.0 10.74 381.9 11.64 406.8 12.47 448.1 14.23 457.6 14.75
14 257.7 7.78 307.4 9.39 357.0 11.12 381.9 12.06 406.8 12.92 448.1 14.74 457.6 15.29
20 257.7 7.89 307.4 9.54 357.0 11.29 381.9 12.23 406.8 13.12 448.1 14.99 457.6 15.53
25 257.7 7.99 307.4 9.66 357.0 11.43 381.9 12.36 406.8 13.28 448.1 15.20 457.6 15.73
30 257.7 8.08 307.4 9.78 357.0 11.57 381.9 12.51 406.8 13.45 448.1 15.41 457.6 15.92
35 257.7 8.20 307.4 9.92 357.0 11.73 381.9 12.69 406.8 13.64 448.1 15.64 457.6 16.18
40 257.7 8.32 307.4 10.06 357.0 11.90 381.9 12.86 406.8 13.83 448.1 15.85 457.6 16.38
45 257.7 8.46 307.4 10.22 357.0 12.09 381.9 13.07 406.8 14.06 448.1 16.12 457.6 16.66
50 257.7 8.59 307.4 10.40 357.0 12.29 381.9 13.29 406.8 14.29 448.1 16.38 457.6 16.92
55 257.7 8.73 307.4 10.59 357.0 12.53 381.9 13.58 406.8 14.57 441.8 16.66 451.3 17.08
60 257.7 9.02 307.4 10.97 357.0 13.05 381.9 14.09 406.8 15.14 430.7 17.19 440.2 17.34
65 257.7 9.21 307.4 11.21 357.0 13.29 381.9 14.38 406.8 15.43 424.4 17.76 433.8 17.89
70 257.7 9.30 307.4 11.30 357.0 13.91 381.9 15.31 399.0 16.79 416.4 18.65 425.9 18.84
75 257.7 9.54 307.4 12.05 357.0 14.89 381.9 16.42 392.8 18.00 410.1 19.53 419.6 19.68
80 255.1 10.83 304.3 13.72 353.4 17.02 373.3 18.79 378.0 20.65 394.9 21.21 404.3 21.39
85 255.1 11.54 304.3 14.65 353.4 18.18 367.2 20.04 371.8 21.90 388.7 22.10 398.1 22.28
90 255.1 13.07 304.3 16.65 351.9 20.65 356.5 22.83 361.1 23.63 377.7 23.81 387.2 24.05
95 255.1 13.86 304.3 17.72 345.7 22.04 350.3 24.37 355.0 24.46 371.5 24.70 380.8 24.92
100 255.1 15.01 304.3 19.17 341.1 23.90 345.7 25.65 350.3 25.79 366.8 26.03 376.1 26.26
105 255.1 16.91 304.3 21.68 330.5 26.97 335.1 27.60 339.6 27.73 355.9 27.97
365.1 28.24
110 255.1 18.99 304.3 24.44 320.3 29.40 321.2 29.55 325.9 29.64 336.1 29.94 337.4 30.22
115 255.1 21.98 304.3 28.11 306.6 30.99 306.6 30.99 308.0 30.99 314.2 31.05 315.6 31.11
118 246.4 20.02 264.6 23.81 266.9 26.06 266.9 26.30 268.2 26.30 273.5 26.35 272.4 26.39
122 196.9 15.19 212.2 18.10 212.8 19.84 213.3 19.89 214.8 19.91 219.6 19.97 219.3 20.05
100%
-9.9 226.5 5.65 270.0 6.81 313.5 8.07 336.0 8.79 369.3 9.52 414.1 10.98 437.3 11.43
-5 226.5 5.95 270.0 7.18 313.5 8.52 336.0 9.28 369.3 10.04 414.1 11.58 437.3 12.06
0 226.5 6.19 270.0 7.48 313.5 8.86 336.0 9.66 369.3 10.44 414.1 12.05 437.3 12.55
5 226.5 6.42 270.0 7.75 313.5 9.18 336.0 10.00 369.3 10.83 414.1 12.49 437.3 13.01
10 226.5 6.61 270.0 7.97 313.5 9.45 336.0 10.29 369.3 11.13 414.1 12.85 437.3 13.38
14 226.5 6.85 270.0 8.26 313.5 9.79 336.0 10.67 369.3 11.54 414.1 13.31 437.3 13.87
20 226.5 7.06 270.0 8.53 313.5 10.10 336.0 10.97 369.3 11.91 414.1 13.70 437.3 14.26
25 226.5 7.24 270.0 8.76 313.5 10.35 336.0 11.22 369.3 12.21 414.1 14.03 437.3 14.59
30 226.5 7.42 270.0 8.97 313.5 10.62 336.0 11.48 369.3 12.52 414.1 14.35 437.3 14.92
35 226.5 7.53 270.0 9.12 313.5 10.79 336.0 11.66 369.3 12.72 414.1 14.59 437.3 15.17
40 226.5 7.66 270.0 9.27 313.5 10.95 336.0 11.84 369.3 12.92 414.1 14.81 437.3 15.40
45 226.5 7.83 270.0 9.47 313.5 11.18 336.0 12.10 369.3 13.19 414.1 15.13 437.3 15.73
50 226.5 7.98 270.0 9.65 313.5 11.42 336.0 12.34 369.3 13.46 414.1 15.43 437.3 16.04
55 226.5 8.11 270.0 9.83 313.5 11.63 336.0 12.60 369.3 13.73 414.1 15.70 432.6 16.28
60 226.5 8.37 270.0 10.18 313.5 12.12 336.0 13.09 369.3 14.27 412.5 16.19 420.3 16.57
65 226.5 8.55 270.0 10.40 313.5 12.34 336.0 13.35 369.3 14.54 406.3 16.72 415.6 17.06
70 226.5 8.82 270.0 10.71 313.5 13.18 336.0 14.50 369.3 16.15 398.6 17.94 406.3 18.25
75 226.5 9.03 270.0 11.42 313.5 14.10 336.0 15.55 369.3 17.31 392.5 18.78 401.7 19.02
80 226.5 10.26 270.0 13.00 313.5 16.13 336.0 17.80 369.3 19.86 381.6 20.40 389.4 20.67
85 226.5 10.92 270.0 13.88 313.5 17.23 336.0 18.99 367.7 21.06 375.5 21.24 384.7 21.53
90 226.5 12.38 270.0 15.77 313.5 19.56 336.0 21.63 355.3 22.72 364.6 22.90 372.4 23.24
95 226.5 13.13 270.0 16.79 313.5 20.88 336.0 23.09 350.8 23.53 358.4 23.75 367.7 24.09
100 226.5 14.18 270.0 18.12 313.5 22.59
330.0 24.25 344.7 24.74 353.7 24.97 361.7 25.33
105 226.5 15.94 270.0 20.41 311.8 25.40 320.9 25.98 334.3 26.50 343.0 26.74 351.4 27.10
110 226.5 17.80 270.0 22.92 308.2 27.57 315.2 27.70 321.5 28.21 326.7 28.50 332.6 28.90
115 226.5 20.46 270.0 26.17 293.4 28.86 302.4 28.86 310.0 29.29 312.8 29.35 314.2 29.55
118 226.5 20.64 236.9 24.55 255.4 24.27 263.3 24.49 269.9 24.86 272.4 24.91 271.3 25.07
122 193.8 18.69 189.9 18.67 203.6 18.48 210.3 18.52 216.2 18.82 218.7 18.88 218.4 19.05
