Outdoor Units Information
■ Cooling Only
Unit
System(HP)
Model Combination unit
Independent unit
Product Charge kg
CF(Correction Factor) kg
Max. Connectable No. of Indoor Units
Net Weight kg
Dimensions mm
(WxHxD) inch
Connecting Pipes Liquid Pipes[mm(inch)]
Gas Pipes[mm(inch)]
1 Outdoor Unit
56810
ARUV50LT2 ARUV60LT2 ARUV80LT2 ARUV100LT2
ARUV50LT2 ARUV60LT2 ARUV80LT2 ARUV100LT2
4.5 4.5 4.5 8
0010
8(12) 10(12) 13(20) 16(25)
175 175 175 240
806x1607x730 806x1607x730 806x1607x730 1280x1607x730
31.7x63.3x28.7 31.7x63.3x28.7 31.7x63.3x28.7 50.4x63.3x28.7
9.52 (3/8) 9.52 (3/8) 9.52 (3/8) 9.52 (3/8)
15.88 (5/8) 19.05 (3/4) 19.05 (3/4) 22.2 (7/8)
Unit
System(HP)
Model Combination unit
Independent unit
Product Charge kg
CF(Correction Factor) kg
Max. Connectable No. of Indoor Units
Net Weight kg
mm
Dimensions
(WxHxD)
inch
Connecting Pipes Liquid Pipes[mm(inch)]
Gas Pipes[mm(inch)]
1 Unit 2 Units
12 14 16 18
ARUV120LT2 ARUV140LT2 ARUV160LT2 ARUV180LT2
ARUV120LT2 ARUV140LT2 ARUV160LT2 ARUV120LT2
ARUV60LT2
8 8 8 4.5+8
1231
20(30) 23(35) 26(40) 29(36)
285 285 285 175+285
1280x1607x730 1280x1607x730 1280x1607x730 (1280x1607x730)
+(806X1607X730)
50.4x63.3x28.7 50.4x63.3x28.7 50.4x63.3x28.7 (50.4x63.3x28.7)
+(31.7x63.3x28.7)
12.7 (1/2) 12.7 (1/2) 12.7 (1/2) 15.88 (5/8)
28.58 (1 1/8) 28.58 (1 1/8) 28.58 (1 1/8) 28.58 (1 1/8)
Unit
System(HP)
Model Combination unit
Independent unit
Product Charge kg
CF(Correction Factor) kg
Max. Connectable No. of Indoor Units
Net Weight kg
mm
Dimensions
(WxHxD)
inch
Connecting Pipes Liquid Pipes[mm(inch)]
Gas Pipes[mm(inch)]
2 Units
20 22 24 26
ARUV200LT2 ARUV220LT2 ARUY240LT2 ARUY260LT2
ARUV140LT2 ARUV160LT2 ARUV140LT2 ARUV160LT2
ARUV60LT2 ARUV60LT2 ARUV100LT2 ARUV100LT2
4.5+8 4.5+8 8x2 8x2
2323
32(40) 35(44) 39(48) 42(52)
175+285 175+285 240+285 240+285
(1280x1607x730) (1280x1607x730) (1280x1607x730) (1280x1607x730)
+(806X1607X730) +(806X1607X730) x 2 x 2
(50.4x63.3x28.7) (50.4x63.3x28.7) (50.4x63.3x28.7) (50.4x63.3x28.7)
+(31.7x63.3x28.7) +(31.7x63.3x28.7) x 2 x 2
15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 19.05 (3/4)
28.58 (1 1/8) 28.58 (1 1/8) 34.9 (1 3/8) 34.9 (1 3/8)
