LG Multi V Plus II System User Manual

38 Outdoor Unit
Refrigerant piping installation
Connection between outdoor and outdoor unit
■ Example of Pipe Connection between Outdoor
1. Pipe Connection between Outdoors
Less than 10 m
h1
Less than 2 m
2. In case pipe length between outdoors is less than 2m
Differnce in height between outdoor units
Less than 5m( h1
5m).
Longest Pipe Length between Outdoors
Less than 10m, after 1st branch.
