32 Outdoor Unit
Refrigerant piping installation
1 Outdoor Unit
Example : 6 Indoor Units connected
: Outdoor Unit
: 1st branch
: Indoor Units
: Sealed piping
L 150m
40m
H 100m
10m or
less
L 100m
L 150m
40m
Slave
Master
Slave
Master
2 Outdoor Units
Example : 6 Indoor Units connected
: Outdoor Unit
: Header branch
: Indoor Units
: Sealing
: Connection branch pipe
between Outdoor units:
ARCNN20
◆ Header Method
