LG RL2 User Manual

5 Appendix
Appendix24
Appendix
5
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Dimensions (W x H x D) Approx. 353 mm x 420 mm x 292 mm
Operating temperature 5 °C to 35 °C
Operating humidity 60 %
Inputs
Portable in (AUX IN) 2.0 Vrms (3.5 mm stereo jack) x 1
Microphone (MIC) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 40 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 80 dB
Bus Power Supply (USB) 5 V
0
500 mA
Battery
Battery type 12 V/7.0 Ah (Valve Regulated Lead-Acid rechargeable battery)
Operating time
Approx. 15 hours (Based on fully charging the battery and continuous
playback using 50 % volume level.)
It may vary depending on the battery status and operational
conditions.
Charging time
Approx. 9 hours
It may vary depending on the battery status and operational
conditions.
y
Design and specications are subject to change without notice.

LG RL2 Specifications

General

Magnetically shielded	No
Woofer	Yes
Speaker type	-
Woofer diameter	165.1 mm
Tweeter diameter	20 mm
Number of drivers	2
Speaker placement	Floor
Audio output channels	- channels
Impedance	75 Ω
Sensitivity	87 dB
RMS rated power	35 W
Product color	Black, Red
Volume control	Rotary
Recommended usage	Stage
AC input voltage	100 - 240 V
DC input voltage	12 V
Power source type	AC, Battery
Power consumption (standby)	0.5 W
Power consumption (typical)	36 W
Headphone outputs	1
Connectivity technology	Wireless
Package depth	366 mm
Package width	440 mm
Package height	456 mm

Weight and Dimensions

Depth	292 mm
Width	353 mm
Height	420 mm
Weight	- g
